Eaton Shielded Wirewound Surface Mount Inductor with Ferrite Core 220 μH ±20% 1.51 A IDC DR125-221-R

Eaton DR125-221-R shielded wirewound surface mount inductor with a ferrite core offers 220 μH inductance with ±20% tolerance and supports a maximum DC current of 1.51 A. This component is engineered to operate reliably at temperatures up to 125°C, making it compatible with demanding industrial and electronic applications.

The inductor features a magnetically shielded wirewound construction that effectively minimizes electromagnetic interference, ensuring signal integrity in sensitive circuits. It comes in a 0125 package case size and is supplied on reels, facilitating efficient placement in automated PCB assembly lines.

With a low DC resistance of 384 mΩ, this surface mount inductor reduces power losses, enhancing overall circuit efficiency. Its compact dimensions (12.5 mm length, 6 mm height, and 12.5 mm depth) allow for space-saving designs in electronic devices.

Typical applications include use in computers, DVD players, portable devices, LCD panels, and DC-DC converters such as buck, boost, and resonant converters. The component complies with RoHS standards, reflecting its environmental compliance.

Features a ferrite core for improved magnetic performance. Magnetically shielded wirewound construction reduces EMI. Surface mount termination style compatible with automated manufacturing. High maximum operating temperature of 125°C.

Packaging on reels for production efficiency. Compact size for integration in space-constrained devices. Inductance tolerance of ±20% supports consistent electrical characteristics. Designed for industrial, computing, and consumer electronics applications.
