Eaton 0704 Shielded Wirewound Surface Mount Inductor with Ferrite Core 150μH ±20% 810mA DR74-151-R

Eaton DR74-151-R is a magnetically shielded wirewound surface mount inductor designed with a ferrite core, providing an inductance of 150μH with ±20% tolerance and rated for a maximum DC current of 810mA. This component is housed in a compact 0704 package measuring 7.6mm in depth, 4.35mm in height, and length of 7.6mm, making it ideal for space-constrained printed circuit board applications.

The inductor is constructed for high power density and efficiency, featuring wirewound coil technology with magnetic shielding to reduce electromagnetic interference. It operates reliably within a wide temperature range from -40°C to 125°C, ensuring durability in demanding industrial electronic environments.

This device's low maximum DC resistance of 591mΩ contributes to efficient current flow and reduced power loss. Its maximum self-resonant frequency of 100kHz supports stable operation in high-frequency switching power supplies, including applications such as DC-DC converters, noise filtering, buck, boost, forward, and resonant converters.

The DR series inductors are RoHS compliant, guaranteeing adherence to environmental regulations. Packaged on reels, this product supports streamlined automated component placement processes in manufacturing.

Common applications for the Eaton DR74-151-R include computers, DVD players, portable electronic devices, LCD panels, and various power conversion equipment deployed in industrial, commercial, and consumer electronics sectors.

Magnetically shielded wirewound design ensures low electromagnetic interference. Compact 0704 package with 7.6mm length and 4.35mm height suitable for dense PCB layouts. Ferrite core construction delivers high power density and efficiency.

Surface mount termination style for automated assembly compatibility. Reliable operation between -40°C and 125°C environment temperatures. Maximum DC resistance is low at 591mΩ for efficient current handling. RoHS compliant ensuring environmental safety standards.

Maximum self-resonant frequency of 100kHz for stable high-frequency performance. Packaged on reels ready for use in industrial and commercial electronics manufacturing. Explore more Surface Mount Inductors and components within the Electronics Components category on EnvMart to meet diverse industrial design requirements.
