Samtec FTS Series Straight Surface Pin Header 60 Contacts 1.27 mm Pitch 2 Row Unshrouded FTS-130-03-L-D

Free Delivery in India | Lowest Global Shipping Charges

Samtec FTS Series Straight Surface Pin Header 60 Contacts 1.27 mm Pitch 2 Row Unshrouded FTS-130-03-L-D

Name: Samtec FTS Series Straight Surface Pin Header 60 Contacts 1.27 mm Pitch 2 Row Unshrouded FTS-130-03-L-D
Brand: Samtec
SKU: 130515
Price: 8.84 USD
Availability: InStock



Category PCB Headers Brand Samtec Condition New

Specifications

Country of Origin	India
Brand	Samtec
Orientation	Straight
Current	1.75A
Model	FTS-130-03-L-D
Mount Type	Surface
Housing Material	Liquid Crystal Polymer
Contact Material	Phosphor Bronze
Series	FTS
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	1.27mm
Contact Plating	Gold
Number of Contacts	60
Contact Gender	Male
Shrouded/Unshrouded	Unshrouded
Connector System	Board-to-Board, Wire-to-Board
Mating Pin Length	1.65mm

Key Features

This pin header features a 1.27 mm pitch spacing and 2 rows of contacts.
It is unshrouded and has a straight orientation for surface mounting.
Contacts are made of phosphor bronze with 0.25 μm gold plating for durability and conductivity.
The housing is constructed from liquid crystal polymer for excellent thermal and mechanical stability.
The connector supports a current rating of 1.75 A at 80 °C.
Operating temperature range is from -55 °C to 125 °C for versatile industrial applications.
Termination is via solder with a mating pin length of 1.65 mm.
Designed for through-hole mount in low-profile terminal strip assemblies.

Product Description

Samtec FTS-130-03-L-D is a Straight Surface Pin Header in the FTS Series offering 60 contacts arranged in 2 rows with a fine 1.27 mm pitch.

Constructed using high-quality phosphor bronze contacts plated with 0.25 μm gold, it ensures excellent electrical conductivity and resistance to corrosion. The liquid crystal polymer housing provides thermal stability and a low-profile form factor, making it ideal for dense PCB designs.

Rated at a current of 1.75 A at 80 °C, this connector performs reliably in demanding environments with temperature tolerance from -55 °C to 125 °C. The termination is solder type, suitable for through-hole mounting on PCBs with surface mount techniques. The 1.65 mm mating pin length assures secure mechanical and electrical connection interfacing with compatible sockets or IDC cable assemblies.

This product is widely applicable across industrial electronics, manufacturing assemblies, telecommunications, computing hardware, and other sectors requiring dependable and compact pin header connectors.

60 contacts in 2 rows with 1.27 mm pitch for high-density connections. Phosphor bronze contact material with gold plating for enhanced conductivity and corrosion resistance. Liquid crystal polymer housing ensures durability and thermal stability.

Current rating of 1.75 A at 80 °C supports medium power applications. Temperature range from -55 °C to 125 °C accommodates harsh environments. Straight orientation and unshrouded design enable versatile board-to-board or wire-to-board connections.

Solder termination for robust and reliable PCB mounting.

This Samtec FTS Series Pin Header is suitable for electronics manufacturing, industrial equipment, telecommunications, and other applications that require reliable, compact, and high-density electrical connectors. Explore more PCB Headers and connectors in EnvMart's extensive catalog.
