Wurth Elektronik WE-LHMI 4020 Shielded Multilayer Surface Mount Inductor with Composite Iron Powder Core 680nH 744373240068
Specifications
| Country of Origin | India |
|---|---|
| Brand | Wurth Elektronik |
| Height | 1.8mm |
| Length | 4.06mm |
| Depth | 4.06mm |
| Packaging | Tape & Reel |
| Series | WE-LHMI |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Composite Iron Powder |
| Inductance | 680nH |
| Standards/Approvals | IEC 61249-2-21, RoHS, REACH, JEDEC JS709B |
| Package/Case | 4020 |
| Maximum DC Current | 5.5A |
| Maximum DC Resistance | 19mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 90MHz |
| Inductor Construction | Wirewound |
| Automotive Standard | AEC-Q200 |
Key Features
- This inductor has a package size of 4020 with a length and depth of 4.06mm each and a height of 1.8mm.
- The component is designed for high current applications with a maximum DC current rating of 5.5A.
- The inductor construction is wirewound and features magnetic shielding to reduce interference.
- It operates over a temperature range from -40°C to 125°C and meets automotive standard AEC-Q200.
- The maximum DC resistance is 19 milliohms, providing efficient power handling.
- This part is RoHS, REACH, and JEDEC JS709B compliant ensuring environmental and quality standards.
- The maximum self-resonant frequency is 90MHz, suited for high frequency power supply circuits.
- Terminal style is surface mount allowing easy PCB placement and soldering.
Product Description
Wurth Elektronik 744373240068 is a shielded multilayer surface mount inductor featuring a composite iron powder core and wirewound construction. It offers an inductance of 680nH with ±20% tolerance, operating at a maximum DC current of 5.5A. Encased in a compact 4020 package measuring 4.06mm by 4.06mm with a height of 1.8mm, this inductor is magnetically shielded to minimize electromagnetic interference in sensitive electronic circuits.
Designed for automotive and industrial applications, it complies with the AEC-Q200 standard and environmental directives including RoHS, REACH, and JEDEC JS709B. The device is suitable for DC-DC converters, power supplies for FPGA, POL converters, and battery-powered devices that require stable inductance under high transient current conditions.
It operates reliably across a wide temperature range from -40°C up to 125°C, making it versatile for various environmental conditions. The component exhibits a low DC resistance of just 19 milliohms, improving efficiency in power circuits. Its maximum self-resonant frequency of 90MHz ensures optimal performance in high-frequency switching power applications.
Packaging includes tape and reel format suitable for automated assembly lines. The surface mount termination style facilitates quick installation on PCB layouts, supporting streamlined manufacturing processes.
Compact 4020 package with shielded multilayer design reduces electromagnetic interference. Composite iron powder core enhances inductance stability and current handling. High maximum DC current rating of 5.5A for demanding applications.
Wide operating temperature range from -40°C to +125°C supports diverse environments. Compliance with automotive and international standards ensures reliability. Low resistance of 19mΩ minimizes power losses. Ideal for power electronics in automotive, communication, and industrial sectors.
Wurth Elektronik inductors like the 744373240068 model are commonly used in industrial electronics, telecommunications, automotive, and power management systems due to their reliable performance and compact size. Explore the Electronics Components > Surface Mount Inductor category on EnvMart for more high-quality inductors and related components.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This inductor has an inductance value of 680nH with a tolerance of ±20%.
The maximum DC current rating for this model is 5.5A, making it suitable for high current applications.
The 4020 package has dimensions of 4.06mm in length and depth, with a height of 1.8mm.
The maximum self-resonant frequency of this inductor is 90MHz, which is ideal for high-frequency applications.
It operates reliably over a temperature range from -40°C to 125°C.
This inductor features a surface mount termination style, allowing for easy PCB placement and soldering.
The core material of this inductor is composite iron powder, which enhances inductance stability.
Yes, it complies with automotive standard AEC-Q200 and environmental directives including RoHS, REACH, and JEDEC JS709B.
The maximum DC resistance is 19 milliohms, which helps minimize power losses in circuits.
This inductor features a wirewound construction, which contributes to its performance characteristics.
The inductor is packaged in tape and reel format, suitable for automated assembly processes.
It is suitable for applications such as DC-DC converters, power supplies for FPGA, POL converters, and battery-powered devices.
