Wurth Elektronik 220 μH Shielded Wirewound Surface Mount Inductor 1.3 A Idc 744770222
Specifications
| Country of Origin | India |
|---|---|
| Diameter | 8mm |
| Brand | Wurth Elektronik |
| Height | 8mm |
| Length | 12mm |
| Depth | 12mm |
| Packaging | Tape & Reel |
| Series | WE-PD |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 220μH |
| Standards/Approvals | RoHS, REACH |
| Package/Case | 1280 |
| Maximum DC Current | 1.3A |
| Pin Count | 2 |
| Maximum DC Resistance | 390mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 3.8MHz |
| Inductor Construction | Wirewound |
| Automotive Standard | AEC-Q200 |
| Recommended solder profile | Reflow |
Key Features
- Magnetically shielded design ensures low leakage field for minimal interference.
- Constructed with a ferrite core for reliable inductance stability.
- Wirewound inductor construction provides high current handling capability.
- Operating temperature range from -40°C to 125°C supports demanding environments.
- Compact package size 1280 optimized for surface mount technology.
- Maximum DC resistance of 390 mΩ helps reduce power loss and heat generation.
- Complies with RoHS and REACH environmental standards.
- Recommended for switching regulators, integrated DC/DC converters, and high efficiency power electronics.
Product Description
Wurth Elektronik 744770222 Shielded Wirewound Surface Mount Inductor features a 220 μH inductance and a maximum DC current rating of 1.3 A. This wirewound inductor incorporates a ferrite core and is magnetically shielded, resulting in low leakage fields and minimal electromagnetic interference, making it ideal for high-performance power electronics.
The inductor is housed in a 1280 package with dimensions of 12 mm length, 8 mm diameter, and 8 mm height, designed for surface mount applications. It can operate reliably within a temperature range from -40°C to 125°C, suitable for industrial, automotive, and consumer electronics environments.
Its low maximum DC resistance of 390 mΩ contributes to low self-losses and efficient energy storage. The inductor is RoHS and REACH compliant and meets automotive standard AEC-Q200, ensuring quality and environmental friendliness.
Magnetically shielded version offers low leakage field. Ferrite core construction enhances inductance stability. Wirewound construction supports high current load capabilities. Operating temperature range from -40°C to 125°C.
Compact surface mount design with 1280 package size. Maximum DC resistance of 390 mΩ minimizes power loss. Meets RoHS and REACH standards for environmental compliance. Certified to automotive standard AEC-Q200 for reliability.
Suitable for use in switching regulators and integrated DC/DC converters.
This inductor is widely used in industrial electronics, automotive power supplies, telecommunications, and computing devices requiring efficient energy management. It is perfect for designers targeting high efficiency and reduced EMI in compact form factors.
Explore more electronic components from Wurth Elektronik and related Surface Mount Inductors to fulfill your project requirements at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this surface mount inductor is 220 μH.
This model has a maximum DC current rating of 1.3 A.
The dimensions of the 1280 package are 12 mm in length, 8 mm in diameter, and 8 mm in height.
It operates reliably within a temperature range from -40°C to 125°C.
The maximum DC resistance is 390 mΩ, which helps reduce power loss.
This inductor is constructed with a ferrite core and features a wirewound design.
It complies with RoHS and REACH environmental standards and is certified to automotive standard AEC-Q200.
The recommended solder profile for this inductor is reflow.
This inductor features a wirewound construction, which supports high current handling capabilities.
It is recommended for use in switching regulators, integrated DC/DC converters, and high efficiency power electronics.
The maximum self-resonant frequency of this inductor is 3.8 MHz.
This inductor is manufactured in India.
