TRACOPOWER DC/DC Converter 15V DC Output 100mA, 36V DC Max Input, Surface Mount THL 3-2423WISM
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | Converters / DC-DC Converters TRACOPOWER THL 3WISM DC/DC Converter, 15V dc/ 100 |
| Brand | TRACOPOWER |
| Efficiency | 80% |
| Length | 24mm |
| Model | THL 3-2423WISM |
| Depth | 8mm |
| Mount Type | Surface |
| Series | THL 3WISM |
| Maximum Operating Temperature | 85°C |
| Package Type | Surface Mount |
| Minimum Operating Temperature | -40°C |
| MTBF | 300000h |
| Number of outputs | 2 |
| Maximum Output Power | 3W |
| Maximum Input Voltage | 36V dc |
| Minimum Input Voltage | 9V |
| Output Voltage 1 | 15V dc |
| Output Current 1 | 100mA |
| Isolation Voltage | 1.5kV dc |
| Input Ratio | 4:1 |
| Input Ratio 4 | 1 |
| Load derating | 2.2% / K above +60°C |
Key Features
- It delivers a maximum output power of 3 watts with 80% efficiency.
- The device includes two outputs isolated at 1500 V DC for enhanced safety.
- It offers remote On/Off control and short circuit protection for reliable operation.
- Operating temperature ranges from -40°C to 85°C, suitable for industrial environments.
- Compact surface mount package measuring 24mm length and 8mm depth.
- MTBF is rated at 300,000 hours ensuring high reliability.
- Meets EMC standards EN55022 Class A and qualified for lead-free reflow soldering process.
- Ideal for data communications, telecommunications, instrumentation, and industrial electronics applications.
Product Description
TRACOPOWER THL 3-2423WISM is a high-performance DC/DC converter with a fully regulated 15V DC output at 100 mA and a maximum output power of 3 watts. Designed for surface mount applications, this converter supports a wide 4:1 input voltage range from 9V to 36V DC and provides two isolated outputs each rated for 1500 V DC isolation. It is equipped with short circuit protection and remote On/Off control, ensuring reliable and safe use in demanding industrial settings.
This compact converter package measures 24mm in length and 8mm in depth, making it suitable for space-limited PCB designs. The device operates reliably over a wide temperature range of -40°C to 85°C and has a high MTBF of 300,000 hours, demonstrating robust durability.
With an efficiency rating of around 80%, the THL 3-2423WISM series minimizes energy losses and heat generation. It is designed to meet EMC requirements to EN55022 Class A and FCC part 15 without the need for additional external filtering components. It is compatible with lead-free soldering processes, aimed at environmentally conscious applications.
This DC/DC converter is ideal for use in telecommunications equipment, data communication interfaces, instrumentation devices, and industrial electronic systems where stable and isolated power conversion is essential.
This converter features an ultra-wide 4:1 input voltage range between 9V and 36V DC. It delivers a maximum output power of 3 watts with 80% efficiency. The device includes two outputs isolated at 1500 V DC for enhanced safety.
It offers remote On/Off control and short circuit protection for reliable operation. Operating temperature ranges from -40°C to 85°C, suitable for industrial environments. Compact surface mount package measuring 24mm length and 8mm depth.
MTBF is rated at 300,000 hours ensuring high reliability. Meets EMC standards EN55022 Class A and qualified for lead-free reflow soldering process. Ideal for data communications, telecommunications, instrumentation, and industrial electronics applications.
Manufactured in Taiwan, Province of China. Explore EnvMart's comprehensive range of DC/DC Converters and power supply solutions for industrial and electronic system applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum output power of this converter is 3 watts.
It supports a wide input voltage range from 9V to 36V DC.
The efficiency rating of this model is approximately 80%.
This converter provides two outputs, each isolated at 1500 V DC.
The surface mount package measures 24mm in length and 8mm in depth.
The operating temperature range is from -40°C to 85°C.
Yes, it is equipped with short circuit protection for reliable operation.
The MTBF (Mean Time Between Failures) is rated at 300,000 hours.
Yes, it is qualified for lead-free reflow soldering processes.
It meets EMC standards EN55022 Class A and FCC part 15 without the need for additional external filtering components.
This model is ideal for telecommunications, data communication, instrumentation, and industrial electronics applications.
It uses a surface mount type for installation.
