TRACOPOWER 10 Watt Medical Grade DC/DC Converter 15V DC Output 670mA, 9V DC Input, Wide 2:1 Input Ratio THM 10-0513

TRACOPOWER THM 10-0513 is a 10 Watt medical grade DC/DC converter designed for demanding applications requiring reliable isolation and low leakage current. The converter provides a 15V DC output at 670mA current with a wide 2:1 input voltage range from 4.5V to 9V DC. It features a compact DIP-24 plastic package for easy PCB integration.

This series complies with IEC/EN/ES 60601-1 3rd edition medical standards, offering 2 x Means of Patient Protection (MOPP) and 5000 VAC RMS isolation voltage, making it suitable for safety-critical medical equipment. Leakage current is exceptionally low, under 2 μA, ensuring patient safety.

The converter operates efficiently with up to 87% efficiency and supports a wide temperature range from -40°C to +90°C, allowing use in harsh environments including transportation, control, measurement systems, and IGBT driver circuits. With an MTBF of 3,850,000 hours, it promises high reliability and long operational life.

Quality is assured through compliance with ISO 13485 and risk management under ISO 14971 standards. The THM 10 series is a reliable and compact solution for industrial, laboratory, medical, and commercial electronics power conversion needs.

Medical certification meeting IEC/EN/ES 60601-1 3rd edition with 2 x MOPP protection. Reinforced isolation voltage rated at 5000 VAC RMS. Low leakage current less than 2 μA for safety critical applications. Wide operating temperature range from -40°C to +90°C.

Compact DIP-24 plastic package suitable for PCB mounting. High efficiency of up to 87% reduces heat generation and improves reliability. Designed for medical, transportation, control, measurement and IGBT driver applications.

Mean time between failures (MTBF) of 3,850,000 hours ensures long-term operation. Certified quality management system conformance to ISO 13485 and ISO 14971 risk management. For advanced power conversion solutions in medical, industrial, and commercial equipment, explore the TRACOPOWER THM 10 series and related DC/DC Converters at EnvMart.
