Vishay TRANSZORB Uni-Directional TVS Diode 600 W Peak Pulse Power 54 V DO-214 SMBJ54A-E3/52

Vishay SMBJ54A-E3/52 Uni-Directional TVS Diode delivers transient voltage suppression to protect electronic circuits from damage induced by voltage spikes and transients. This discrete semiconductor device is housed in a low profile DO-214 surface mount package, optimizing it for automated assembly processes. With a robust peak pulse power dissipation rating of 600 watts measured with a 10/1000 µs waveform, it ensures high reliability when clamping sudden voltage surges in industrial, automotive, telecommunications, and consumer electronic applications.

The diode provides a minimum breakdown voltage of 60 volts and a maximum reverse stand-off voltage of 54 volts, clamping voltage at 87.1 volts, making it suitable for protecting sensitive semiconductor elements like ICs and MOSFETs from inductive load switching and lightning-induced transients. Operating temperature ranges from -55 °C to 150 °C, enabling stable function under harsh environmental conditions.

This TVS diode features a glass passivated chip junction, offering long-term stability and low incremental surge resistance for excellent clamping performance. It incorporates ESD protection to prevent damage from electrostatic discharge and meets the AEC-Q101 automotive standard, validating its quality and reliability for automotive electronic systems. The device is ideal for use on signal lines of sensor units and power lines in industrial, commercial, and telecommunication equipment.

Uni-directional transient voltage suppressor designed for surface mount technology. 600 W peak pulse power dissipation capability withstands high energy spikes. Temperature operating range from -55 °C to +150 °C ensures versatility.

Automotive qualified under AEC-Q101 for demanding environments. Compact DO-214 package supports automated assembly and space-saving designs. Fast response time minimizes transient spike duration to protect circuitry. Low leakage current of 1µA maintains circuit efficiency under normal operation.

Single element per chip designed for optimal transient suppression.

Set yourself up with reliable and high-performance transient voltage suppression using the Vishay SMBJ54A-E3/52 TVS Diode. Perfect for engineers and manufacturers across industrial, automotive, telecommunications, and consumer electronic sectors seeking robust surge protection solutions. Explore more TVS Diodes and semiconductor components to match your project requirements on EnvMart.
