Hirose Circular Connector Miniature Panel Mount Socket Female 4 Contacts IP67, IP68 125V LF10WBR-4S
Specifications
| Country of Origin | Japan |
|---|---|
| Voltage | 125V |
| Brand | Hirose |
| Orientation | Straight |
| Current | 10A |
| Model | LF10WBR-4S |
| IP Rating | IP67, IP68 |
| Mount Type | Panel Mount |
| Housing Material | Zinc Alloy |
| Contact Material | Bronze |
| Series | LF |
| Termination Type | Solder |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -25°C |
| Pole Format | 4 |
| Contact Plating | Gold |
| Number of Contacts | 4 |
| Contact Gender | Female |
| Shell Size | 10 |
| Mating Type | Bayonet |
| Connector Size | Miniature |
| Plug/Socket | Socket |
Key Features
- This connector features a bayonet lock mating type for secure and quick connections.
- Constructed with a zinc alloy housing and gold-plated bronze contacts for durability and reliable conductivity.
- Designed for solder termination and supports a temperature range from -25°C to 85°C.
- The shell size is 10 with straight orientation and miniature size suitable for compact industrial applications.
- It provides excellent sealing against dust and water, making it suitable for harsh environments.
- Ideal for industrial, electronic, power, and manufacturing applications requiring robust circular connectors.
Product Description
Hirose LF10WBR-4S is a high-quality miniature circular connector designed for panel mount applications. This socket connector features 4 female contacts and supports a nominal voltage of 125V and a current rating of 10A, making it suitable for a wide range of industrial and electronic uses.
The connector is constructed with a durable zinc alloy housing and gold-plated bronze contacts, ensuring long-lasting performance and corrosion resistance. It utilizes a bayonet type mating mechanism for secure and quick connection and disconnect cycles. Its IP67 and IP68 ratings guarantee protection against dust ingress and water immersion, providing reliable operation even in challenging environments.
The operating temperature range spans from -25°C to 85°C, accommodating various industrial settings. The termination type is solder, designed for robust and permanent electrical connections. Its compact, miniature shell size 10 with straight orientation enables installation into confined spaces without compromising reliability.
This connector is engineered primarily for industrial, power, manufacturing, and electronic applications where compact, durable, and sealed connectors are essential. Its design adheres to the LF Series standards from Hirose, focusing on ease of shielding termination and connector assembly.
This connector supports 4 contacts with female contact gender. Mount type is panel mount, suitable for chassis integration. Contact plating is gold for improved electrical conductivity and wear resistance. It is recommended for applications requiring IP67 and IP68 sealed connectors.
Made in Japan, reflecting high manufacturing standards and quality.
For engineers, designers, and manufacturers seeking reliable miniature circular connectors with robust environmental protection, the Hirose LF10WBR-4S is an excellent choice. Browse the Industrial Circular Connectors category at EnvMart for related products and solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Hirose LF10WBR-4S has a nominal voltage rating of 125V and a current rating of 10A.
This model is rated IP67 and IP68, providing excellent protection against dust ingress and water immersion.
The connector features a zinc alloy housing and gold-plated bronze contacts, ensuring reliable conductivity and corrosion resistance.
It operates within a temperature range of -25°C to 85°C, suitable for various industrial environments.
The Hirose LF10WBR-4S is designed with 4 female contacts.
This connector uses solder termination for robust and permanent electrical connections.
The connector has a shell size of 10 and features a straight orientation, making it suitable for compact installations.
It utilizes a bayonet type mating mechanism, allowing for secure and quick connections.
The Hirose LF10WBR-4S is designed for panel mount applications, suitable for chassis integration.
This connector is made in Japan, reflecting high manufacturing standards.
It is ideal for industrial, electronic, power, and manufacturing applications that require robust circular connectors.
The Hirose LF10WBR-4S is classified as a miniature connector, suitable for confined spaces.
