Amphenol Limited MIL Spec Circular Connector 15 Way 22A 700V Copper Alloy Male Straight Cable Mount, 62GB-56T14-15PN
Specifications
| Country of Origin | United Kingdom |
|---|---|
| Voltage | 700V |
| Brand | Amphenol Limited |
| Orientation | Straight |
| Current | 22A |
| Model | 62GB-56T14-15PN |
| Mount Type | Cable |
| Housing Material | Aluminium Alloy |
| Contact Material | Copper Alloy |
| Series | 62 GB |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Contact Plating | Gold |
| Number of Contacts | 15 |
| Contact Gender | Male |
| Connector Gender | Male |
| Shell Size | 14 |
| Military Standard | MIL-DTL-26482 |
| Mating Type | Bayonet |
| Connector Size | Standard |
| Shell Plating | Aluminium Alloy |
Key Features
- Features 15 male contacts for versatile multi-circuit use.
- Operates at up to 22A and 700V for robust signal and power transmission.
- Straight cable mount with bayonet coupling for secure and durable installation.
- Copper alloy contacts and gold plating ensure excellent conductivity and corrosion resistance.
- Aluminium alloy housing with strain relief and neoprene grommet delivers moisture sealing and environmental protection.
- Wide operating temperature range from -55°C to 125°C supports harsh environments.
- Designed to MIL-DTL-26482 standard for military and industrial reliability.
- Shell size 14 and standard connector size for broad compatibility in system design.
Product Description
Amphenol Limited 62GB-56T14-15PN MIL Spec Circular Connector is engineered for applications requiring rugged, high-performance electrical connectivity in industrial and military environments. This circular connector features 15 male copper alloy contacts, designed for a maximum current carrying capacity of 22A and a voltage rating up to 700V. Its straight, cable-mount orientation and bayonet mating type provide both ease of assembly and a secure, vibration-resistant connection in use.
The robust aluminium alloy shell, combined with gold-plated contacts, offers a balance of mechanical durability and reliable electrical performance. A resilient neoprene insulator and rear wire sealing grommet provide a liquid-tight seal, ensuring protection against moisture ingress and environmental contaminants. The built-in strain relief feature further secures cable assemblies, preventing stress at the termination points and extending connector life in demanding installations.
The housing complies with MIL-DTL-26482 standards, ensuring interchangeability and compatibility with other military-grade circular connectors. Shell size 14 and a standard connector interface make integration straightforward across a wide range of systems, enabling multi-circuit power and signal transmission in one compact assembly.
The 62 GB series’ precision-engineered keyways help to prevent mismating among multiple connectors, enhancing system reliability in critical applications. Gold-plated copper alloy contacts guarantee minimal contact resistance and excellent corrosion resistance, maximizing signal integrity over the connector’s lifespan. The robust aluminium shell is equally suitable for use with brass or stainless steel variants for specialized needs.
Typical use cases include industrial control systems, field equipment, heavy machinery, avionics, transportation, and military vehicles, where consistent power and signal connections are required under exposure to vibration, moisture, temperature extremes, and contaminants.
Explore more Industrial Circular Connectors on EnvMart to meet your precise connectivity requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This connector has a maximum current carrying capacity of 22A and a voltage rating of up to 700V.
The contacts are made of copper alloy and feature gold plating to ensure excellent conductivity and corrosion resistance.
It operates within a temperature range of -55°C to 125°C, making it suitable for harsh environments.
This model features 15 male contacts, allowing for versatile multi-circuit use.
It is designed for straight cable mounting, which facilitates secure installation.
The housing is made from aluminium alloy, providing mechanical durability and environmental protection.
It is designed to meet the MIL-DTL-26482 standard, ensuring reliability in military and industrial applications.
This model uses a bayonet mating type, which provides a secure and vibration-resistant connection.
The shell size for this connector is 14, which is a standard size for compatibility in system designs.
Yes, it includes a built-in strain relief feature that helps secure cable assemblies and prevent stress at termination points.
Typical use cases include industrial control systems, field equipment, heavy machinery, avionics, transportation, and military vehicles.
The connector is made in the United Kingdom, ensuring adherence to quality standards.
