Souriau Sunbank by Eaton Circular Connector, 79 Contacts, Cable Mount, Standard Size 20 Plug, Male, IP67, 1000V 8STA62035PN

Souriau Sunbank by Eaton 8STA62035PN circular connector plug is a premium cable-mount industrial circular connector featuring 79 contacts. This connector is engineered for high-demand environments, optimized for motorsport and other robust industrial applications requiring lightweight and reliable electrical connections.

Constructed with an aluminium alloy housing that is conductive black zinc plated, it offers excellent resistance to corrosion and mechanical stress. The contacts are gold-plated copper alloy to ensure optimal conductivity and long service life. The connector supports up to 1000 volts and 5 amperes current capacity, meeting demanding electrical performance standards.

Designed according to MIL-DTL-38999 specifications, the 8STA series connectors tolerate shock loads up to 300g for 3 ms and withstand vibrations up to 147 m/s² in the 10-2000 Hz range. This makes the connector ideal for motorsport applications such as Formula 1, Moto GP, WRC, Nascar, and military uses including UAVs, ground vehicles, and infantry systems where size, weight, and resilience are critical.

The connector’s IP67 rating guarantees protection from dust ingress and water immersion up to 1 meter for 30 minutes, suitable for harsh environmental conditions. It features a quick mating bayonet lock that mates in one-third of a turn with an audible click, enabling fast and secure connections. The colour-coded banding facilitates easy identification of connectors.

Operating temperature ranges from -55°C up to 175°C, allowing use in extreme climates. The connector’s straight orientation and standard size 20 shell ensure compatibility with related equipment. Supplied complete with contacts and an extraction tool, it facilitates quick assembly and maintenance.

The connector body is aluminium alloy with conductive black zinc plating for durability. Gold-plated copper alloy contacts ensure reliable electrical performance. Shock resistance of 300g for 3 ms provides robust mechanical performance.

Vibration tolerance of 147 m/s² over 10-2000 Hz reduces connection failures. IP67 rating protects against dust and water ingress in industrial environments. Bayonet mating system offers fast, secure one-third turn connections.

Operating temperature range of -55°C to 175°C suits extreme applications. Designed primarily for motorsport and military with lightweight construction. Supplied with contacts and extraction tools included for installation ease.

This Souriau Sunbank by Eaton circular connector is a perfect solution for applications demanding compact, lightweight, and highly reliable electrical connectors. Explore more Industrial Circular Connectors and related products at EnvMart.
