Vishay 100 nF 20V DC Tantalum Capacitor Surface Mount Tape & Reel TMCP1D104KTRF
Specifications
| Country of Origin | Japan |
|---|---|
| Voltage | 20V dc |
| Brand | Vishay |
| Height | 1.2mm |
| Length | 2mm |
| Model | TMCP1D104KTRF |
| Depth | 1.25mm |
| Technology | Tantalum |
| Packaging | Tape & Reel |
| Mount Type | Surface |
| Series | TMCP |
| Maximum Operating Temperature | 125°C |
| Capacitance | 100nF |
| Minimum Operating Temperature | -55°C |
| Polarity | Polar |
| Terminal type | Solder |
| Dissipation Factor | 6% |
| Leakage Current | 0.5μA |
| Electrolyte Type | Solid |
| Standards/Approvals | EIA-717, RoHS |
| Package/Case | 2012-12 |
| Equivalent Series Resistance ESR | 33Ω |
| Tolerance ± | -10% |
| Terminations | 100 % matte tin |
Key Features
- Capacitance of 100 nanofarads for stable electrical performance.
- Surface mount package type with Tape & Reel packaging for automated assembly.
- Package case size 2012-12 (0805 size) enabling small form factor designs.
- Equivalent Series Resistance (ESR) of 33 Ohms optimizing frequency response.
- Polarized tantalum capacitor with solid electrolyte for enhanced reliability.
- Operating temperature range from -55°C to 125°C for industrial environments.
- Standards compliant including EIA-717 and RoHS for quality assurance.
- Low dissipation factor of 6% ensuring efficient operation.
Product Description
Vishay TMCP1D104KTRF is a tantalum capacitor with a capacitance of 100nF and a voltage rating of 20V DC, designed as a surface mount device suitable for modern electronic assembly processes.
This capacitor uses solid electrolyte technology housed in a 2012-12 case size (equivalent to 0805), allowing compact and high-density circuit designs. Its Equivalent Series Resistance (ESR) is specified at 33 Ohms, providing a good balance for filtering and bypass applications.
The TMCP series capacitors feature low leakage current at 0.5μA and a dissipation factor of 6%, making them energy efficient with minimal power loss, crucial for reliable performance in audio, visual, and general industrial equipment.
The operating temperature range from -55°C to 125°C ensures suitability in challenging environments including automotive and industrial applications, with compliance to EIA-717 and RoHS standards demonstrating environmental and quality commitments.
The device is polarized with solder-type terminals plated with 100% matte tin, ensuring excellent solderability and secure placement on printed circuit boards. Packaging in Tape & Reel format supports efficient insertion into automated manufacturing lines.
100nF capacitance for versatile electronics use. 20V maximum operating DC voltage rating. Small 0805 (2012-12) surface mount package. Solid electrolyte tantalum construction. 33Ω ESR for improved frequency characteristics.
Wide operating temperatures from -55°C to 125°C. Low leakage current of 0.5μA for energy efficiency. RoHS compliant and EIA-717 approved. 100% matte tin terminations for reliable solder joints. Tape & Reel packaging for automated PCB assembly.
Ideal for industrial, audio-visual, and general electronic applications requiring stable capacitance and robust performance. Sourced from Japan ensuring high manufacturing standards. Explore Vishay components and Tantalum Capacitors on EnvMart for quality and reliability in electronics manufacturing.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a capacitance value of 100 nanofarads (nF).
It has a maximum operating voltage rating of 20V DC.
The Equivalent Series Resistance (ESR) is specified at 33 Ohms.
The dimensions are 2mm in length, 1.25mm in depth, and 1.2mm in height.
The operating temperature range is from -55°C to 125°C.
Yes, this capacitor is polarized.
It is packaged in Tape & Reel format for automated assembly.
It is compliant with EIA-717 and RoHS standards.
The dissipation factor is 6%.
The leakage current is specified at 0.5μA.
It features solder-type terminals plated with 100% matte tin.
This capacitor is sourced from Japan.
