TE Connectivity Standard Edge II Series Straight Edge Connector Female 36-Contacts 2 Row 2.54 mm Pitch Through Hole 5530843-3
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 1kV ac |
| Brand | TE Connectivity |
| Orientation | Straight |
| Current | 3A |
| Mount Type | Through Hole |
| Housing Material | Polyethylene Terephthalate |
| Contact Material | Phosphor Bronze |
| Series | Standard Edge II |
| Termination Type | Solder |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold over Nickel |
| Number of Contacts | 36 |
| Contact Gender | Female |
| Connector Gender | Female |
| Card Type | Dual Edge |
Key Features
- This connector features 36 contacts arranged in 2 rows for efficient circuit connection.
- The pitch between contacts is 2.54 mm, suitable for standard PCB spacing.
- It has a through-hole mount type allowing secure soldering to printed circuit boards.
- Constructed with phosphor bronze contacts plated with gold over nickel for durability and reliable electrical performance.
- Designed to operate in temperatures from -55°C up to 85°C ensuring durability in diverse environments.
- Operates at a voltage rating of 1 kV AC and a current rating of 3A for low-power applications.
- Its bifurcated cantilever contact design ensures strong and consistent engagement.
- Made from polyethylene terephthalate housing material, ensuring mechanical strength and electrical insulation.
Product Description
TE Connectivity 5530843-3 Standard Edge II Series Straight Edge Connector Female with 36-Contacts in 2 Rows is engineered for high reliability and economical performance in industrial and electronic applications.
This edge connector is designed for connecting daughter cards to motherboards using a dual edge card type and provides a low profile, industry standard packaging with a 2.54 mm pitch suitable for precise PCB layouts.
The bifurcated gold-plated phosphor bronze contacts deliver strength and high electrical reliability, making it ideal for DC to DC converters, low wattage power supplies, and industrial-grade card extenders.
The connector's polyethylene terephthalate housing ensures robust insulation and strong mechanical support while withstanding operating temperatures between -55°C and 85°C.
Featuring intercontact keying slots for exact card orientation with a mating daughter card that accommodates keying plugs, this connector reduces assembly errors and enhances device durability.
The 3A current and 1 kV ac voltage rating make it suitable for low-cost I/O applications requiring durable and rugged card edge contacts in industrial, manufacturing, and electronic equipment settings.
36 gold over nickel plated phosphor bronze contacts arranged in 2 rows. Through hole mount with solder termination for reliable PCB connection. Operating temperature range from -55°C to 85°C. Polyethylene terephthalate housing for insulation and durability.
Intercontact keying slots for correct card orientation. Dual edge card type for robust mechanical engagement. Low profile standard edge II series for compact design requirements.
This Edge Connector is a versatile component in electronics manufacturing and industrial equipment assembly, supporting reliable and efficient electrical connections. Ensure compatibility with your specific daughter card and motherboard design by checking connector pitch and contact arrangements.
Explore more high quality electronic connectors and components from TE Connectivity at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It has a voltage rating of 1 kV AC, making it suitable for low-power applications.
The current rating is 3A, which is appropriate for its intended applications.
The pitch between contacts is 2.54 mm, which is standard for PCB spacing.
This connector features 36 contacts arranged in 2 rows.
It utilizes a through-hole mount type, allowing for secure soldering to printed circuit boards.
The contacts are made from phosphor bronze and are plated with gold over nickel, while the housing is made from polyethylene terephthalate.
It operates within a temperature range of -55°C to 85°C, suitable for diverse environments.
Yes, it features intercontact keying slots for exact card orientation, reducing assembly errors.
It supports a dual edge card type, designed for connecting daughter cards to motherboards.
The termination type is solder, ensuring a reliable connection to the PCB.
The country of origin for this connector is India.
