Molex C-Grid III Series Straight Through Hole Pin Header 24 Contacts 2.54 mm Pitch 1 Row Unshrouded 90120-0784
Specifications
| Country of Origin | Ireland |
|---|---|
| Voltage | 350V |
| Brand | Molex |
| Orientation | Straight |
| Current | 3A |
| Mount Type | Through Hole |
| Housing Material | Polyester |
| Contact Material | Brass |
| Series | C-Grid III |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 24 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 2.9mm |
| Mating Pin Length | 6.75mm |
Key Features
- Designed for wire-to-board applications with through-hole mounting.
- Constructed with a gold-plated brass contact and polyester housing for durability.
- Unshrouded design allows easy pin access and breakaway capability for custom sizing.
- Suitable for operating voltage up to 350V and current rating of 3A.
- Operating temperature range from -55°C to 125°C ensures reliability in harsh environments.
- Provides high mechanical stability and secure mating connection after soldering.
- Compatible with C-Grid III series PCB sockets and crimp housings.
- Ideal for industrial, computer, medical, telecommunications, consumer, and automotive applications.
Product Description
Molex 90120-0784 C-Grid III Series Straight Through Hole Pin Header is engineered with precision to deliver secure, reliable connections in a 24-contact, single-row layout with 2.54 mm pitch. Its straight orientation and through-hole mount type optimize compatibility for wire-to-board integrations.
Manufactured using gold-plated brass contacts and a robust polyester housing, this header ensures exceptional conductivity and mechanical integrity. The unshrouded design supports flexibility with breakaway features, enabling customization according to design needs.
Operating safely under voltages up to 350V and currents of 3A, it maintains functionality across a wide temperature range from -55°C to 125°C. The pins provide high retention force for a secure mating connection and once soldered to PCBs, exhibit excellent mechanical stability essential for demanding industrial and commercial applications.
This header is an integral component of the Molex C-Grid III interconnection system, compatible with matching PCB sockets and crimp housings. It supports use in environments such as industrial equipment, computer systems, medical devices, telecommunications, transport electronics, and consumer products.
Designed for versatile wire-to-board connection applications. Enables customization with breakaway pin sections. Gold plating offers enhanced corrosion resistance and conductivity. Reliable under high mechanical strain and temperature extremes.
Ensures secure mating with high pin retention forces. Widely used in diverse industrial and consumer electronic sectors. Manufactured to meet high industry standards in Ireland. Explore more premium PCB connectors and headers through EnvMart to suit various electronic and industrial connectivity requirements.
Explore more products in our PCB Pin Header category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It has a maximum operating voltage rating of 350V.
This model is rated for a maximum current of 3A.
The pitch size is 2.54 mm.
It is constructed with gold-plated brass contacts and a polyester housing.
The operating temperature range is from -55°C to 125°C.
This model features 24 contacts in a single row layout.
It uses a through-hole mounting type for installation.
It is compatible with C-Grid III series PCB sockets and crimp housings.
The termination type is solder, allowing for secure connections.
The tail pin length is 2.9 mm.
It is suitable for industrial, computer, medical, telecommunications, consumer, and automotive applications.
It is manufactured in Ireland.
