Molex C-Grid III Series Straight Through Hole Pin Header, 5 Contacts, 2.54 mm Pitch, 1 Row, Unshrouded, 3A, 350V 90120-0765
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 350V |
| Brand | Molex |
| Orientation | Straight |
| Current | 3A |
| Mount Type | Through Hole |
| Housing Material | Polyester |
| Contact Material | Brass |
| Series | C-Grid III |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 5 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 2.9mm |
| Mating Pin Length | 6.75mm |
Key Features
- Features a single row unshrouded pin header suitable for through hole mounting.
- Constructed with brass contacts plated in gold for reliable conductivity and corrosion resistance.
- Rated for a current of 3 amperes and voltage up to 350 volts.
- Includes solder tail pins with a tail length of 2.9 mm for secure PCB attachment.
- Operating temperature range spans from -55°C to 125°C ensuring performance in varied environments.
- Designed with a breakaway style allowing customization of pin count for design flexibility.
- High retention force pins provide secure mating with C-Grid III sockets and crimp housings.
- Applicable in industrial, computer, medical, telecommunications, and transportation sectors.
Product Description
Molex 90120-0765 C-Grid III Series Straight Through Hole Pin Header is a high-quality PCB connector featuring 5 gold-plated brass contacts arranged in a single unshrouded row with a 2.54 mm pitch. Rated for 3A current and 350V voltage, it supports reliable wire-to-board connections in demanding industrial, computer, medical, telecommunications, and transportation applications.
Designed with a solder termination type and a tail pin length of 2.9 mm, the header ensures robust solder joint strength and mechanical stability once mounted on PCBs. Its breakaway design provides flexibility by allowing the pins to be cut to the desired size, accommodating various design needs.
The contacts maintain high retention force for secure mating with corresponding C-Grid III sockets and crimp housings. Operating temperature ranges from -55°C up to 125°C, making it suitable for diverse environmental conditions.
This connector system supports a wide range of uses including computers, servers, medical equipment, industrial machinery, and automotive electronic safety systems. The straight orientation and through-hole mount type further ensure stable fitment and ease of integration.
Features a single row of 5 male contacts with gold plating for enhanced conductivity. Breakaway style pins allow design flexibility and customization. Polyester housing material provides durability and insulation. Rated for 3A current and 350V voltage for safe and efficient power transmission.
Suitable for use in industrial, telecommunications, consumer electronics, and medical devices. Unshrouded design enables reliable mating with appropriate counterparts. High mechanical stability once soldered ensures long-term performance.
Discover the comprehensive Molex C-Grid III range for efficient PCB interconnection solutions at EnvMart, suited for modern industrial and electronic design challenges.
Explore more products in our PCB Pin Header category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model is rated for a maximum current of 3 amperes.
It has a voltage rating of 350 volts.
The contacts are arranged with a pitch of 2.54 mm.
The operating temperature range spans from -55°C to 125°C.
This model features 5 male contacts.
The tail pin length is 2.9 mm.
It uses a solder termination type for secure mounting.
The contacts are constructed from brass and are gold-plated for conductivity.
The housing is made of polyester, providing insulation and durability.
This model is designed as an unshrouded pin header.
It is applicable in industrial, computer, medical, telecommunications, and transportation sectors.
The country of origin for this product is India.
