Molex C-Grid III Series Straight Through Hole Pin Header 12 Contact 2.54 mm Pitch 1 Row Unshrouded 90120-0132
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 350V |
| Brand | Molex |
| Orientation | Straight |
| Current | 3A |
| Mount Type | Through Hole |
| Housing Material | Polyester |
| Contact Material | Brass |
| Series | C-Grid III |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Tin |
| Number of Contacts | 12 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 2.9mm |
| Mating Pin Length | 6.75mm |
Key Features
- Supports a current rating of 3 Amperes for reliable electrical performance.
- Constructed with polyester housing and brass contacts plated with tin for durability.
- Offers a breakaway design allowing customized length and flexibility in design.
- Male contact gender with a tail pin length of 2.9 mm and mating pin length of 6.75 mm.
- Operates reliably within temperature range of -55°C to 125°C.
- Intended for wire-to-board applications with straight orientation.
- Provides a high retention force and mechanical stability after soldering.
- Compatible with C-Grid III series PCB sockets and crimp housings for board-to-board and wire-to-board interconnection.
Product Description
Molex 90120-0132 C-Grid III Series Straight Through Hole Pin Header is a high-quality wire-to-board connector designed for robust PCB interfacing. It features 12 male contacts arranged in a single unshrouded row with a 2.54 mm pitch, suitable for through hole mounting methods. The contacts are made of brass with tin plating, ensuring excellent conductivity and corrosion resistance. Polyester housing provides mechanical support and durability.
This series supports a maximum current rating of 3 Amperes and can operate within a temperature range of -55°C to 125°C, making it suitable for demanding electronic applications. The breakaway design allows the header to be cut to desired lengths, providing flexible design options for PCB layouts.
The pin header exhibits a high retention force for secure mating and mechanical stability once soldered to the PCB, ensuring reliable electrical connections in industrial, computer, medical, consumer, telecommunications, and transportation equipment. This product is ideal for applications such as desktop PCs, servers, medical devices, white goods, industrial machinery, and automotive electronics systems.
Key features include male contact gender, tail pin length of 2.9 mm, mating pin length of 6.75 mm, and a straight orientation. The connector accommodates a voltage rating of 350V. Supports a current rating of 3 Amperes for reliable electrical performance.
Constructed with polyester housing and brass contacts plated with tin for durability. Offers a breakaway design allowing customized length and flexibility in design. Male contact gender with a tail pin length of 2.9 mm and mating pin length of 6.75 mm.
Operates reliably within temperature range of -55°C to 125°C. Intended for wire-to-board applications with straight orientation. Provides a high retention force and mechanical stability after soldering. Compatible with C-Grid III series PCB sockets and crimp housings for board-to-board and wire-to-board interconnection.
Explore Molex products and related PCB headers for your electronics manufacturing needs on EnvMart.
Explore more products in our PCB Pin Header category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum current rating of this pin header is 3 Amperes, ensuring reliable electrical performance.
The contacts in this model have a pitch of 2.54 mm, suitable for through hole mounting.
It operates reliably within a temperature range of -55°C to 125°C, making it suitable for demanding applications.
The housing is made of polyester, and the contacts are made of brass with tin plating for enhanced conductivity and corrosion resistance.
The tail pin length of this connector is 2.9 mm, while the mating pin length is 6.75 mm.
Yes, it is compatible with C-Grid III series PCB sockets and crimp housings for board-to-board and wire-to-board interconnection.
This model features a straight orientation, intended for wire-to-board applications.
This pin header has 12 male contacts arranged in a single row.
The termination type for this connector is solder, suitable for secure PCB connections.
The country of origin for this product is India.
This model uses a wire-to-board connector system, designed for robust PCB interfacing.
The pin header exhibits a high retention force, providing mechanical stability after soldering for reliable electrical connections.
