Molex Micro-Fit 3.0 Series Straight Through Hole PCB Header, 12 Contacts, 3 mm Pitch, 2 Row, Shrouded 43045-1224
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 250V |
| Brand | Molex |
| Orientation | Straight |
| Current | 5A |
| Mount Type | Through Hole |
| Housing Material | High Temperature Thermoplastic |
| Contact Material | Brass |
| Series | Micro-Fit 3.0 |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 2 |
| Pitch | 3mm |
| Contact Plating | Tin |
| Number of Contacts | 12 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
| Mating Pin Length | 3mm |
Key Features
- Supports up to 5A current for reliable power distribution.
- Constructed with high temperature thermoplastic housing suitable for IR reflow soldering.
- Shrouded dual-row design enhances connection security and prevents accidental disconnections.
- Through hole mount compatible with SMT processes, reducing production costs.
- Features brass contacts with tin plating for excellent conductivity and corrosion resistance.
- Operating temperature range from -40°C to 105°C ensures durability across environments.
- Equipped with metal press-fit retention clips for secure PCB mounting.
- Positive latching mechanism provides secure mating connection.
Product Description
Molex 43045-1224 PCB Header from the Micro-Fit 3.0 Series is a high-performance, dual-row straight through hole connector featuring 12 contacts with a 3 mm pitch. Rated for 5A current, it provides reliable and compact power distribution solutions in electronic assemblies.
The housing is made from high temperature thermoplastic material that withstands temperatures up to 265°C during infrared reflow soldering processes. This PCB header is shrouded to ensure secure mating and prevent accidental disconnection, making it ideal for applications requiring robust electrical connections.
Designed for through hole mounting with SMT compatibility, this connector reduces processing complexity and manufacturing costs. Its brass contacts with tin plating ensure optimal electrical conductivity and resistance to corrosion.
Operating reliably in environments from -40°C to 105°C, the connector utilizes metal press-fit retention clips to secure its position on the PCB. The positive latching with locking ramps further enhances connection stability.
This Micro-Fit 3.0 Series PCB header is suitable for various low to mid power industrial and electronic uses including consumer appliances, data communications, telecommunications, medical devices, solar power systems, military commercial off-the-shelf equipment, and gaming terminals.
Supports up to 5A current for reliable power distribution. Constructed with high temperature thermoplastic housing suitable for IR reflow soldering. Shrouded dual-row design enhances connection security and prevents accidental disconnections.
Through hole mount compatible with SMT processes, reducing production costs. Features brass contacts with tin plating for excellent conductivity and corrosion resistance. Operating temperature range from -40°C to 105°C ensures durability across environments.
Equipped with metal press-fit retention clips for secure PCB mounting. Positive latching mechanism provides secure mating connection. Suitable for low to mid power applications in electronic and industrial equipment. Explore more Molex power connectors and PCB Headers at EnvMart for your electronic component needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a current rating of up to 5A, making it suitable for reliable power distribution in electronic assemblies.
The contacts in this PCB header have a pitch of 3 mm, which is standard for the Micro-Fit 3.0 Series.
It features a housing made from high temperature thermoplastic and brass contacts with tin plating for optimal conductivity and corrosion resistance.
The operating temperature range for this PCB header is from -40°C to 105°C, ensuring functionality across various environments.
This model includes 12 contacts, arranged in a dual-row configuration.
It is designed for through hole mounting, which is compatible with surface mount technology (SMT) processes.
The termination type for this model is solder, allowing for secure connections on the PCB.
Yes, it has a shrouded design and a positive latching mechanism that enhances connection security and prevents accidental disconnections.
This connector is rated for a maximum voltage of 250V, suitable for various applications.
The contacts in this PCB header are male, designed for wire-to-board connections.
It is suitable for low to mid power applications in consumer appliances, telecommunications, medical devices, and more.
The country of origin for this model is India.
