Microchip 16 bit Digital Signal Processor 40 MHz 64kB FLASH 44-Pin TQFP dsPIC33FJ64GP804-I/PT
Specifications
| Country of Origin | India |
|---|---|
| Brand | Microchip |
| Height | 1mm |
| Length | 10mm |
| Model | dsPIC33FJ64GP804-I/PT |
| Width | 10mm |
| Mount Type | Surface |
| Maximum Operating Temperature | 85°C |
| Package Type | TQFP |
| Minimum Operating Temperature | -40°C |
| Ram size | 16kB |
| Pin Count | 44 |
| Automotive Standard | AEC-Q100 |
| Minimum Supply Voltage | 3.3V |
| Program Memory Size | 64kB |
| Maximum Clock Frequency | 40MHz |
| Number of Timers | 5 |
| Instruction Set Architecture | RISC |
| Program Memory Type | FLASH |
| Device Million Instructions per Second | 70MIPS |
Key Features
- Operates at a maximum clock frequency of 40 MHz capable of delivering 70 MIPS performance.
- Features 16 bit data bus width with 16kB of RAM for efficient data processing.
- Utilizes RISC instruction set architecture with 64kB FLASH program memory for fast execution.
- Package type is 44-pin TQFP surface mount for compact PCB design.
- Supports operating temperature range from -40°C to 85°C suitable for harsh environments.
- Incorporates 5 timers and complies with automotive standard AEC-Q100 for reliability.
- Designed for applications including digital filter algorithms, precision motor control, and power supply management.
Product Description
Microchip dsPIC33FJ64GP804-I/PT is a high-performance 16 bit Digital Signal Processor operating at 40 MHz with 64kB FLASH memory and a 44-pin TQFP package. It is engineered to combine the capabilities of a DSP with the ease of use of an MCU, delivering up to 70 MIPS for advanced digital signal processing tasks.
This digital signal controller features a 16 bit data bus, 16kB RAM, and a RISC instruction set to optimize speed and efficiency. The surface mount package and compact dimensions of 10mm by 10mm with a 1mm height support modern embedded system designs requiring low profile components.
The processor includes 5 integrated timers and meets automotive-grade standard AEC-Q100, ensuring robust reliability for automotive and industrial applications. It operates across a wide temperature range from -40°C to 85°C, suitable for demanding environmental conditions.
Ideal for industrial, automotive, and consumer electronics, this dsPIC33F model excels in executing digital filter algorithms, precision motor control, high-speed digital power supply management with SMPS peripherals, analog comparators, and fast ADC conversions. It enables designers to develop high-performance control systems with integrated hardware features specifically tailored for digital power and motor control.
Compact size, rich feature set, and automotive standard compliance make this device well-suited for commercial, industrial, and automotive embedded systems requiring efficient digital signal processing capabilities.
Operates at a maximum clock frequency of 40 MHz capable of delivering 70 MIPS performance. Features 16 bit data bus width with 16kB of RAM for efficient data processing. Utilizes RISC instruction set architecture with 64kB FLASH program memory for fast execution.
Package type is 44-pin TQFP surface mount for compact PCB design. Supports operating temperature range from -40°C to 85°C suitable for harsh environments. Incorporates 5 timers and complies with automotive standard AEC-Q100 for reliability.
Compact dimensions: 10mm length, 10mm width, and 1mm height. Designed for applications including digital filter algorithms, precision motor control, and power supply management. Explore the extensive Microchip Digital Signal Processor range at EnvMart to find solutions for your industrial, automotive, and embedded electronics development needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum clock frequency of this model is 40 MHz.
It features 64kB of FLASH program memory for fast execution.
The operating temperature range is from -40°C to 85°C, making it suitable for harsh environments.
This model includes 16kB of RAM for efficient data processing.
It incorporates 5 integrated timers for various applications.
The package type is 44-pin TQFP, designed for surface mounting.
This model complies with the automotive standard AEC-Q100 for reliability.
It features a 16 bit data bus width.
The height of this model is 1mm.
It is designed for applications including digital filter algorithms, precision motor control, and power supply management.
The dsPIC33FJ64GP804-I/PT delivers up to 70 MIPS performance for advanced digital signal processing tasks.
The minimum supply voltage required for this model is 3.3V.
