Panasonic 2.2nF 16V dc 16V ac Surface Mount Film Capacitor ECHU1C222GX5
Specifications
| Country of Origin | India |
|---|---|
| Brand | Panasonic |
| Height | 0.7mm |
| Length | 1.6mm |
| Model | ECHU1C222GX5 |
| Width | 0.8mm |
| Mount Type | Surface |
| Series | ECHU(X) |
| Maximum Operating Temperature | 125°C |
| Capacitance | 2.2nF |
| Standards/Approvals | RoHS |
| Rated AC Voltage | 16V ac |
| Rated DC Voltage | 16V dc |
Key Features
- Constructed using stacked metallised PPS film enabling compact and lightweight design.
- Rated maximum operating temperature of 125°C suitable for demanding environments.
- Mould-less structure enhances reliability and manufacturability for reflow soldering processes.
- Low equivalent series resistance (ESR) ensures efficient performance in time-constant and filtering circuits.
- Ideal for oscillation, resonance, audio circuits, and filtering applications in electronics.
- Complies with RoHS directive for environmental safety and material compliance.
Product Description
Panasonic ECHU1C222GX5 Surface Mount Film Capacitor features a capacitance of 2.2nF and is rated for 16 volts DC and AC operation, designed for compact and lightweight electronic applications. Manufactured with stacked metallised PPS film, the capacitor offers a mould-less construction that withstands operating temperatures up to 125°C, making it suitable for industrial, electronics manufacturing, and precision filtering tasks.
This film capacitor is optimized for reflow soldering processes, providing excellent reliability in surface mount technology (SMT) applications. The low equivalent series resistance (ESR) characteristic helps maintain signal integrity and filter efficiency in audio circuits, oscillation, and resonance circuits.
Designed for usage in time-constant applications, this capacitor complies with the RoHS directive ensuring environmental and material compliance. Its compact size with 1.6mm length, 0.8mm width, and 0.7mm height supports design flexibility for dense circuit boards.
Typical use cases include industrial electronics, consumer electronics, communication equipment, and advanced laboratory devices requiring stable and reliable passive components for filtering and timing applications.
Constructed using stacked metallised PPS film enabling compact and lightweight design. Rated maximum operating temperature of 125°C suitable for demanding environments. Mould-less structure enhances reliability and manufacturability for reflow soldering processes.
Low equivalent series resistance (ESR) ensures efficient performance in time-constant and filtering circuits. Ideal for oscillation, resonance, audio circuits, and filtering applications in electronics. Complies with RoHS directive for environmental safety and material compliance.
This Panasonic capacitor series ECHU(X) is well-suited for a wide range of industrial and commercial electronics assemblies. For more components in this category browse Electronics Components > Film Capacitors at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The capacitance of this model is 2.2nF.
It is rated for 16V DC and 16V AC operation.
The maximum operating temperature is 125°C, making it suitable for demanding environments.
This model supports surface mounting.
It has dimensions of 1.6mm length, 0.8mm width, and 0.7mm height.
It is constructed using stacked metallised PPS film, which contributes to its compact and lightweight design.
This film capacitor is ideal for oscillation, resonance, audio circuits, and filtering applications in electronics.
Yes, it complies with the RoHS directive for environmental safety and material compliance.
It features a low equivalent series resistance (ESR), ensuring efficient performance in time-constant and filtering circuits.
The country of origin for this capacitor is India.
This model belongs to the ECHU(X) series.
It is suitable for use in industrial electronics, consumer electronics, communication equipment, and advanced laboratory devices.
