Panasonic ECQE(F) Polyester Film Capacitor 220 nF 250V AC 250V DC Through Hole Mount ECQE2224JF
Specifications
| Country of Origin | India |
|---|---|
| Brand | Panasonic |
| Height | 10.5mm |
| Length | 12mm |
| Model | ECQE2224JF |
| Width | 5.5mm |
| Mount Type | Through Hole |
| Series | ECQE(F) |
| Maximum Operating Temperature | 105°C |
| Capacitance | 220nF |
| Rated AC Voltage | 250V ac |
| Rated DC Voltage | 250V dc |
| Lead Pitch | 10mm |
| Lead Diameter | 0.6mm |
| Automotive Standard | AEC-Q200 |
Key Features
- Rated AC voltage of 250 volts and DC voltage of 250 volts for reliable performance.
- Compact size with dimensions of 12mm length, 10.5mm height, and 5.5mm width.
- Lead pitch of 10mm with 0.6mm lead diameter suitable for through-hole mounting.
- Complies with automotive standard AEC-Q200 for high reliability.
- Maximum operating temperature is 105°C making it suitable for demanding environments.
- Self-healing, non-inductive capacitor construction ensuring excellent electrical characteristics.
- Standards compliance includes CSA E60384-14, EN 60384-14, and UL 60384-14 certifications.
Product Description
Panasonic ECQE2224JF Film Capacitor is a polyester film capacitor designed for through-hole mounting with a capacitance of 220 nF and voltage ratings of 250V AC and 250V DC. This capacitor features metallised polyester film construction combined with a flame retardant epoxy resin coating, ensuring durability and safety in electrical circuits.
The ECQE(F) series capacitors are self-healing and non-inductive, providing excellent electrical performance. With a compact form factor of 12mm length, 10.5mm height, and 5.5mm width, and lead pitch of 10mm, it is easy to integrate into various PCB layouts.
This capacitor complies with the automotive AEC-Q200 standard, making it suitable for automotive and industrial applications. It is rated for a maximum operating temperature of 105°C, ensuring reliable function in harsh environments.
Additionally, the product meets several safety standards including CSA E60384-14, EN 60384-14, and UL 60384-14, guaranteeing compliance with international quality benchmarks. The non-inductive design and self-healing properties enhance its lifespan and efficiency in circuits.
Rated AC and DC voltage of 250V each. Flame retardant epoxy resin coating for increased safety. Compliant with automotive and international standards. Compact dimensions and suitable lead pitch for through-hole mounting.
High operating temperature tolerance up to 105°C. Non-inductive and self-healing film capacitor construction.
Ideal for general-purpose applications in electronics, automotive, and industrial sectors. Panasonic ECQE2224JF capacitors provide reliable performance while supporting efficient PCB integration and thermal stability.
Explore EnvMart's Electronics & Electricals category for a wide range of Film Capacitors and related components to meet your design and manufacturing needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The capacitance of this model is 220 nF.
It has rated AC and DC voltages of 250V each.
The capacitor has dimensions of 12mm in length, 10.5mm in height, and 5.5mm in width.
The maximum operating temperature is 105°C, making it suitable for demanding environments.
The lead pitch is 10mm, and the lead diameter is 0.6mm, suitable for through-hole mounting.
It complies with the automotive standard AEC-Q200, ensuring high reliability.
This model is designed for through-hole mounting.
It features metallised polyester film construction and a flame retardant epoxy resin coating.
It meets several safety standards including CSA E60384-14, EN 60384-14, and UL 60384-14.
The capacitor is self-healing and non-inductive, providing excellent electrical performance.
It is suitable for general-purpose applications in electronics, automotive, and industrial sectors.
The country of origin for the Panasonic ECQE2224JF is India.
