TE Connectivity 0805 Unshielded Wirewound Surface Mount Inductor 1 μH ±5% 170 mA Idc, Ferrite Core, 36502A1R0JTDG

TE Connectivity presents the 36502A1R0JTDG 0805 Unshielded Wirewound Surface Mount Inductor, engineered for precise electronics applications requiring reliable inductance and high quality. This surface mount inductor offers a nominal inductance of 1 μH with a tight tolerance of ±5%, delivering consistent performance in power and signal conditioning circuits.

Constructed with a ferrite core and wirewound technology, this inductor maintains a high quality factor of at least 20 and a maximum self-resonant frequency of 100 MHz, making it well-suited for high-frequency applications. It handles a maximum DC current of 170 mA and has a maximum DC resistance of 2.5 Ω, ensuring efficient current handling with minimal losses.

The compact 0805 package format with dimensions of 2.29 mm length, 1.52 mm height, and 1.73 mm depth ensures suitability for densely populated printed circuit boards. The device is molded for enhanced mechanical protection and designed for solder termination on standard PCB surfaces.

Operating reliably in temperatures from -40°C to 125°C, this inductor is compliant with RoHS standards, aligning with environmental and safety regulations. Packaged on reels, it supports automated insertion techniques to improve manufacturing efficiency.

Compact 0805 package suitable for high-density PCB layouts. Wirewound construction providing high quality factor and low resistance. Ferrite core ensuring stability and high self-resonant frequency up to 100 MHz. Rated for operating temperature range from -40°C to 125°C.

RoHS compliant and molded for durability. Inductance tolerance of ±5% enables precise performance in circuit design. Maximum DC resistance of 2.5 Ω to minimize power loss. Reel packaging designed for automated PCB assembly processes.

This inductor is ideal for use in electronic devices requiring reliable passive component performance including consumer electronics, industrial controls, automotive electronics, and communication equipment. Its precise inductance and thermal robustness make it a versatile component in various electrical designs.

Explore more passive components and inductors in the TE Connectivity series via EnvMart’s extensive electronics component catalog to support your design and manufacturing needs.
