TDK 1-Element Bi-Directional TVS Diode, 1.6 kW, 2-Pin SOD-523 B72500D0090A060

TDK B72500D0090A060 is a 1-Element Bi-Directional Transient Voltage Suppressor (TVS) Diode designed to protect electronic circuits from electrostatic discharge (ESD) and transient voltage spikes. Offering a peak pulse power dissipation of 1.6 kW and enclosed in a compact 2-pin SOD-523 surface-mount package, this diode is ideal for safeguarding sensitive semiconductor components in industrial and consumer electronic applications.

The diode features a bi-directional configuration enabling it to handle voltage transients of both polarities, making it suitable for AC and DC circuits. It has a minimum breakdown voltage of 10 V, a maximum reverse stand-off voltage of 9 V, and clamps transients at a maximum voltage of 30 V, providing effective voltage suppression to protect downstream components.

Engineered for high performance, the diode supports continuous operation between -40°C to 85°C, ensuring reliability under harsh environmental conditions common in industrial, laboratory, telecommunications, and consumer electronics sectors. The device demonstrates excellent ESD protection withstanding over 3000 pulses as per IEC 61000-4-2 Level 4 standards.

The TDK B72500D0090A060 diode's surface-mount design enhances production efficiency by enabling automated assembly on printed circuit boards. Nickel barrier lead-free terminations promote environmentally friendly manufacturing and soldering reliability.

Key specifications include a 2-pin configuration, 0.9 mm width, 0.9 mm height, and 1.75 mm length, making it a compact solution for space-constrained circuit board layouts. It also features a low maximum reverse leakage current of only 1 μA to minimize power dissipation.

Provides robust protection against ESD and voltage transients in electronic circuits. Bi-directional diode configuration suitable for AC and DC voltage clamping. Compact SOD-523 surface-mount package enables easy PCB integration.

Wide operating temperature range from -40°C to 85°C for reliable performance. High peak pulse power rating of 1.6 kW handles high-energy transients safely. Low leakage current reduces overall power consumption in protected circuits.

Compliant with IEC 61000-4-2 Level 4 ESD protection standard. Lead-free nickel barrier terminations promote environmentally friendly compliance.

This diode is well-suited for use in telecommunications equipment, industrial instrumentation, consumer electronics, and automotive electronics where transient voltage protection is critical. It safeguards semiconductor devices, integrated circuits, and sensitive components from damage caused by voltage spikes and electrostatic discharge events.
