STMicroelectronics 1-Element Bi-Directional TVS Diode 1.5 kW Surface Mount 2-Pin SMC Package SM15T33CA
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 2.45mm |
| Length | 7.15mm |
| Model | SM15T33CA |
| Width | 6.25mm |
| Mount Type | Surface |
| Series | SM15T TVS |
| Maximum Operating Temperature | 150°C |
| Package Type | SMC |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Clamping Voltage VC | 59V |
| Diode Configuration | Single |
| Direction Type | Bi-Directional |
| Minimum Breakdown Voltage Vbr | 31.4V |
| Maximum Reverse Stand-off Voltage Vwm | 28.2V |
| Peak Pulse Power Dissipation Pppm | 1.5kW |
| Test Current It | 1mA |
| Maximum Peak Pulse Current Ippm | 169A |
| Maximum Reverse Leakage Current | 1μA |
Key Features
- The diode features a single element configuration for bidirectional voltage protection.
- It mounts on surfaces with a compact 2-pin SMC package for high-density PCB layouts.
- Provides a minimum breakdown voltage of 31.4 V and a maximum reverse stand-off voltage of 28.2 V.
- Operates reliably between -55°C and 150°C, suitable for industrial environment conditions.
- Offers a maximum peak pulse current rating of 169 A and low maximum reverse leakage current of 1 μA.
- Clamping voltage is rated at 59 V to safeguard electronic components from voltage spikes.
- Complies with SM15T TVS series standards but has no specific automotive certification.
Product Description
STMicroelectronics SM15T33CA is a robust 1-element bi-directional Transient Voltage Suppressor (TVS) diode rated for a peak pulse power dissipation of 1.5 kW. This diode is engineered to protect sensitive electronic components from voltage transients such as electrostatic discharge, lightning, and switching surges, ensuring increased reliability in electronic devices.
Featuring a single element diode configuration with bi-directional voltage suppression, it is mounted in a standard surface mount 2-pin SMC package which enables efficient PCB layout with space-saving benefits.
With a minimum breakdown voltage of 31.4 V and a maximum reverse stand-off voltage of 28.2 V, this device effectively clamps voltage spikes to a maximum of 59 V, protecting downstream circuitry. It can handle a peak pulse current of 169 A and maintains a very low reverse leakage current of only 1 μA, contributing to minimal power loss and enhanced energy efficiency.
The diode operates reliably across a wide temperature range from -55°C up to 150°C, making it suitable for demanding industrial, telecommunications, automotive (non-certified), and power supply applications. The compact size with dimensions of 7.15 mm length, 6.25 mm width, and 2.45 mm height suits high-density board designs and industrial equipment.
STMicroelectronics is known for its high-quality semiconductor products which are widely used in electronics manufacturing, laboratory equipment, and electrical systems requiring robust over-voltage protection.
The diode features a single element configuration for bidirectional voltage protection. Surface mount 2-pin SMC package optimizes PCB space. Minimum breakdown voltage of 31.4 V and maximum stand-off voltage of 28.2 V. Peak pulse power dissipation of 1.5 kW with a peak pulse current of 169 A.
Operating temperature range from -55°C to 150°C for industrial applications. Clamping voltage of 59 V protects against voltage spikes. Low maximum reverse leakage current of 1 μA enhances efficiency. Compact dimensions of 7.15 × 6.25 × 2.45 mm suit dense layouts.
This product is an ideal choice for engineers and designers seeking reliable transient voltage suppression in power supplies, industrial controls, and electronic devices. Explore similar TVS Diode options in the Semiconductor category on EnvMart for comprehensive electronics protection solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The SM15T33CA diode has a peak pulse power dissipation rating of 1.5 kW.
The maximum reverse stand-off voltage for this model is 28.2 V.
The clamping voltage is rated at 59 V, which protects against voltage spikes.
It operates reliably between -55°C and 150°C, making it suitable for industrial applications.
The maximum peak pulse current rating is 169 A.
The dimensions are 7.15 mm in length, 6.25 mm in width, and 2.45 mm in height.
This diode features a single element configuration for bi-directional voltage protection.
It comes in a surface mount 2-pin SMC package, which is suitable for high-density PCB layouts.
The minimum breakdown voltage is 31.4 V.
The maximum reverse leakage current is only 1 μA, contributing to minimal power loss.
While it is suitable for automotive applications, it does not have specific automotive certification.
This diode belongs to the SM15T TVS series.
