Molex Pico-Clasp Series Right Angle Surface PCB Header, 3 Contacts, 1 mm Pitch, 1 Row, Shrouded 501568-0307

Molex 501568-0307 Pico-Clasp Series Right Angle Surface PCB Header is a compact wire-to-board connector featuring a 1.00 mm pitch and 3 contacts arranged in a single row, designed for secure and high-density PCB connections.

The connector housing is made from high-quality nylon material, providing excellent insulation and mechanical durability, while the brass contact pins plated with tin ensure reliable electrical conductivity and resistance to corrosion.

This connector supports a current rating of 1A and a voltage of up to 50V, making it suitable for a variety of electronic applications. Its shrouded design guarantees secure mating and prevents accidental disconnections during operation.

Designed for surface mounting, the right angle orientation facilitates easy mounting on printed circuit boards, optimizing space and improving mechanical stability. The mating pin length measures 1 mm to ensure accurate and reliable contact with mating connectors.

Operating temperature ranges from -40°C to 105°C, enabling use in diverse industrial, manufacturing, electronics, and communications environments. This connector is ideal for compact electronic devices requiring wire-to-board interconnections with positive lock mechanisms and high density.

The product is made in Japan and is supplied on reels to improve assembly efficiency in automated production setups. The Molex Pico-Clasp series includes options from 2 to 15 circuits in single row configurations and larger counts in double row formats, accommodating various design requirements.

This PCB header supports a current rating of 1 ampere for reliable power transmission. The housing is constructed of durable nylon material for enhanced insulation and strength. Contact material is brass with tin plating to ensure corrosion resistance and reliable conductivity.

It features a single row design with a surface mount type for easy PCB attachment. Operating temperature ranges from -40°C to 105°C, suitable for various industrial environments. The connector system uses a solder termination type with male contact gender and right angle orientation.

This product is manufactured in Japan and designed for high-density electronic applications.

Explore the complete range of PCB Headers and connectors available at EnvMart to find suitable components for your electronics manufacturing, prototype development, and industrial automation projects.
