Taiwan Semiconductor 1.18 V General Purpose Zener Diode Single 1 W Surface Mount SOD-123W BZD27C18PWH
Specifications
| Country of Origin | India |
|---|---|
| Brand | Taiwan Semiconductor |
| Height | 1.2mm |
| Length | 3.5mm |
| Model | BZD27C18PWH |
| Mount Type | Surface |
| Series | BZD27C |
| Maximum Operating Temperature | 175°C |
| Package Type | SOD-123W |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Automotive Standard | AEC-Q101 |
| Maximum Power Dissipation Pd | 1W |
| Diode Configuration | Single |
| Test Current It | 50mA |
| Maximum Reverse Leakage Current | 1μA |
| Nominal Zener Voltage Vz | 18V |
| Zener Type | General Purpose |
| Maximum Zener Impedance | 10Ω |
Key Features
- The diode features a single element chip for stable voltage reference.
- It supports a maximum power dissipation of 1 watt with low leakage current.
- The SOD-123W surface mount package provides a low profile form factor suitable for compact PCBs.
- The device operates within temperature range from -55°C to 175°C ensuring suitability in harsh environments.
- Maximum zener impedance is 10 ohms at test current providing precise voltage regulation.
- Test current is specified at 50 mA for performance validation.
- Compliance with automotive standard AEC-Q101 and other key approvals guarantees reliability in automotive and industrial applications.
- The device is RoHS and halogen free compliant, ensuring environmental safety.
Product Description
Taiwan Semiconductor BZD27C18PWH is a 1.18 V General Purpose Zener Diode designed for robust voltage regulation, reference voltage, and protection circuits in industrial, automotive, and electronics applications. Packaged in a compact SOD-123W surface mount form factor, this single-element device is engineered to deliver reliable performance with a maximum power dissipation of 1 watt.
This zener diode features low reverse leakage current of 1 μA, a maximum zener impedance of 10 ohms, and is tested at a current of 50 mA to ensure precise voltage regulation at the nominal 18 V rating. The component supports a wide operating temperature range from -55°C to 175°C, offering durability under rigorous environmental conditions.
With compliance to AEC-Q101 automotive standards, Jesd 201 Class 2, J-STD-002 and J-STD-020 MSL level 1, it guarantees high reliability for automotive and industrial circuit designs. The device is also RoHS and halogen-free compliant aligning with IEC 61249-2-21 standards, promoting environmental safety.
The SOD-123W package has a compact length of 3.5 mm and height of 1.2 mm, enabling assembly in space-constrained PCB layouts. This diode is ideal for applications requiring voltage reference, surge current limiting, and general purpose zener regulation in power and signal circuits.
The diode features a single element chip for stable voltage reference. It supports up to 1 watt power dissipation. Compliant with automotive standard AEC-Q101 ensuring high reliability. Design includes low leakage current and low zener impedance characteristics.
Suitable for voltage regulation and protection circuits in industrial and automotive use cases. Surface mount SOD-123W package offers compact footprint integration. Wide operating temperature range from -55°C to 175°C. RoHS and halogen-free compliant for environmental safety.
This product is a dependable choice for design engineers requiring a high-quality voltage reference zener diode in modern electronics assemblies. Browse additional semiconductor and discrete component solutions from Taiwan Semiconductor at EnvMart.
Explore more products in our Zener Diodes category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The nominal zener voltage of this model is 18V, making it suitable for voltage regulation applications.
It supports a maximum power dissipation of 1 watt, which is essential for its operation in various circuits.
This diode operates within a temperature range from -55°C to 175°C, ensuring functionality in harsh environments.
The maximum reverse leakage current is specified at 1 μA, which contributes to its efficiency in voltage regulation.
The maximum zener impedance is 10 ohms at the test current, providing precise voltage regulation.
It is packaged in a SOD-123W surface mount form factor, which is suitable for compact PCB designs.
The SOD-123W package has a height of 1.2 mm and a length of 3.5 mm, allowing for space-efficient assembly.
It complies with the automotive standard AEC-Q101, ensuring reliability for automotive applications.
The test current is specified at 50 mA, which is used to validate the performance of the diode.
This model features a single element chip, which is designed for stable voltage reference.
Yes, it is RoHS and halogen-free compliant, aligning with IEC 61249-2-21 standards for environmental safety.
It is suitable for voltage regulation, reference voltage, and protection circuits in industrial and automotive applications.
