Abracon 25 MHz Crystal ±50 ppm Surface Mount 4-Pin 1.1 mm Height 3.3 mm Length 2.5 mm Width FC3BQBBMM25.0-T3
Specifications
| Country of Origin | India |
|---|---|
| Brand | Abracon |
| Height | 1.1mm |
| Length | 3.3mm |
| Model | FC3BQBBMM25.0-T3 |
| Packaging | Tape & Reel |
| Width | 2.5mm |
| Mount Type | Surface |
| Series | FC3BQ |
| Maximum Operating Temperature | 85°C |
| Package Type | Surface Mount |
| Minimum Operating Temperature | -40°C |
| Standards/Approvals | RoHS |
| Pin Count | 4 |
| Standard Frequency | 25MHz |
| Load Capacitance | 20pF |
Key Features
- Standard frequency is 25 MHz for precise timing applications.
- Surface mount type with 4 pins for compact PCB integration.
- Physical dimensions include 3.3 mm length, 2.5 mm width, and 1.1 mm height.
- Operating temperature range is from -40°C to 85°C for reliability in harsh environments.
- Package is delivered on tape and reel for automated assembly.
- Compliance with RoHS standards ensures environmental safety.
- Shunt capacitance is 3 pF, supporting stable oscillator performance.
- Load capacitance is specified at 20 pF for optimal frequency stability.
Product Description
The Abracon FC3BQBBMM25.0-T3 is a surface mount 25 MHz crystal designed for electronic circuitry requiring precise frequency control. This 4-pin crystal oscillator features a ±50 ppm frequency tolerance and stability, ensuring accurate timing across various applications.
Its compact dimensions of 3.3 mm in length, 2.5 mm in width, and 1.1 mm in height make it ideal for space-constrained PCB assemblies. The device operates reliably within a temperature range of -40°C to 85°C, suitable for industrial, commercial, and consumer electronics.
This crystal belongs to the FC3BQ series with a resin seal and silver termination finish, featuring a shunt capacitance of 3 pF and a load capacitance of 20 pF to maintain frequency precision. The product is compliant with RoHS standards, contributing to environmentally safe manufacturing.
The FC3BQBBMM25.0-T3 is supplied in a tape and reel packaging format, facilitating automated pick-and-place assembly processes used in manufacturing electronics.
Typical applications include industrial control systems, computer motherboards, communications devices, and other electronic oscillator circuits requiring dependable frequency sources.
Standard frequency is 25 MHz for precise timing applications. Surface mount type with 4 pins for compact PCB integration. Physical dimensions include 3.3 mm length, 2.5 mm width, and 1.1 mm height. Frequency tolerance and stability are both ±50 ppm over operating temperature range.
Operating temperature range is from -40°C to 85°C for reliability in harsh environments. Package is delivered on tape and reel for automated assembly. Compliance with RoHS standards ensures environmental safety. Shunt capacitance is 3 pF supporting stable oscillator performance.
Load capacitance is specified at 20 pF for optimal frequency stability. EnvMart offers a complete range of crystals and timing components, including the Abracon FC3BQ series, suitable for electronic manufacturing and engineering needs.
Explore more products in our Crystal Units category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The standard frequency of this model is 25 MHz, designed for precise timing applications.
This crystal has physical dimensions of 3.3 mm in length, 2.5 mm in width, and 1.1 mm in height.
The operating temperature range for this unit is from -40°C to 85°C, making it suitable for harsh environments.
The load capacitance is specified at 20 pF, which supports optimal frequency stability.
It is delivered in tape and reel packaging, facilitating automated assembly processes.
This model uses a surface mount type with 4 pins for compact PCB integration.
The frequency tolerance and stability of this crystal are both ±50 ppm.
Yes, it is compliant with RoHS standards, ensuring environmental safety in its manufacturing.
The shunt capacitance is 3 pF, which supports stable oscillator performance.
This crystal belongs to the FC3BQ series, which features a resin seal and silver termination finish.
Typical applications include industrial control systems, computer motherboards, and communications devices requiring dependable frequency sources.
The country of origin for this model is India.
