Samtec MECF Series Straight Edge Connector Female Surface Mount 10-Contacts 1.27 mm Pitch 2 Row Solder MECF-05-01-L-DV
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 280V ac |
| Brand | Samtec |
| Orientation | Straight |
| Current | 3.5A |
| Model | MECF-05-01-L-DV |
| Mount Type | Surface |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Beryllium Copper Alloy |
| Series | MECF |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 1.27mm |
| Contact Plating | Gold over Nickel, Tin over Nickel |
| Number of Contacts | 10 |
| Contact Gender | Female |
| Connector Gender | Female |
| Card Type | Edge |
| Card Thickness | 1.6mm |
Key Features
- This connector features gold over nickel and tin over nickel contact plating for durability and conductivity.
- Constructed with beryllium copper alloy contacts and a liquid crystal polymer housing for reliable performance.
- Supports currents up to 3.5A and voltage up to 280V AC.
- Operates in temperatures ranging from -55°C to 125°C, suitable for harsh environments.
- Includes keying way to ensure proper mating and has solder termination type.
- Compatible with edge cards of 1.6 mm thickness and designed for industrial electronics applications.
Product Description
Samtec MECF-05-01-L-DV is a high-performance edge connector featuring a straight orientation and female connector gender designed for surface mount PCB applications. This connector offers 10 gold-over-nickel plated contacts arranged in 2 rows with a 1.27 mm pitch, ensuring precise and reliable electrical connections at currents up to 3.5 amps and voltages of 280V AC. It is engineered with beryllium copper alloy contacts and a liquid crystal polymer housing to withstand mechanical stress and thermal cycling.
Its operating temperature range from -55°C to 125°C enables use in demanding industrial, electronic, and power connector scenarios. The solder termination type and inclusion of a keying way ensure secure installation and prevent mismating. The connector supports edge cards with a thickness of 1.6 mm, widely used in computing and communications equipment.
This Samtec MECF series connector is ideal for applications requiring compact, durable, and high-speed signal and power connections such as in laboratory instruments, manufacturing automation equipment, and other electronic assemblies. Its design facilitates PCB vertical mounting with alignment pins.
Key features include gold plating for corrosion resistance, robust contact materials, and adherence to surface mount technology for efficient assembly. Though it lacks specific standards or approvals, its construction supports reliable use in commercial and industrial electronics.
This connector features gold over nickel and tin over nickel contact plating for durability and conductivity. Constructed with beryllium copper alloy contacts and a liquid crystal polymer housing for reliable performance.
Supports currents up to 3.5A and voltage up to 280V AC. Operates in temperatures ranging from -55°C to 125°C, suitable for harsh environments. Includes keying way to ensure proper mating and has solder termination type. Compatible with edge cards of 1.6 mm thickness and designed for industrial electronics applications.
Explore the category for Edge Connectors in Electronics Components at EnvMart for more related connectivity solutions from reputable brands.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports currents up to 3.5A and voltages up to 280V AC.
It operates within a temperature range of -55°C to 125°C, making it suitable for harsh environments.
The connector features beryllium copper alloy contacts and a liquid crystal polymer housing for reliable performance.
This edge connector has a total of 10 contacts arranged in 2 rows.
The contact pitch for this connector is 1.27 mm.
This connector uses a solder termination type for secure installation.
It is compatible with edge cards that have a thickness of 1.6 mm.
Yes, it includes a keying way to ensure proper mating and prevent mismating.
The MECF-05-01-L-DV features a straight orientation.
The connector is manufactured in India.
It is designed for industrial electronics applications, including computing and communications equipment.
The contacts are plated with gold over nickel and tin over nickel for enhanced durability and conductivity.
