TE Connectivity SMA Series Coaxial Connector Cable Female SMA, 50 Ω, Straight Body, Solder Termination 5-1814832-2

TE Connectivity 5-1814832-2 SMA Series Coaxial Connector Cable is a highly reliable female SMA RF connector designed for use with coaxial cable assemblies operating at 50 Ω impedance and frequencies up to 2 GHz. Featuring a straight body orientation, this connector ensures low signal loss and excellent electrical performance.

The connector body is plated with gold, providing superior corrosion resistance in demanding industrial and electronic environments. The contact material is brass, plated with tin to enhance durability and conductivity. Termination is by solder type, offering secure physical and electrical connections.

This SMA series connector has a standard size with an approximate mated outer diameter of 6.35 mm (0.25 inches) and couples via threaded mechanism to provide solid mechanical connection. Its normal polarity female jack design is well suited for RF communication systems, laboratory test equipment, and industrial electronics.

Operational temperature ranges from a minimum of -65°C to a maximum of 85°C, allowing it to perform reliably in harsh conditions. Provides reliable signal transmission up to 2 GHz frequency. Features gold body plating for superior corrosion resistance.

Constructed with brass contact material plated with tin for durability. Suitable for operating temperatures ranging from -65°C to 85°C. Designed as a female SMA jack connector with threaded coupling mechanism. Standard size with 6.35 mm outer diameter ensures compatibility.

Normal polarity design for straightforward integration. Manufactured in China with quality assurance from TE Connectivity.

This Coaxial Connector cable is widely used in industrial electronics, telecommunications, RF testing, and measurement applications due to its robust design and reliable electrical performance. Available through EnvMart for professional-grade electronic component requirements.
