Nexperia 16 V 400 mW Zener Diode Single 2-Pin Surface Mount SOD-323 PDZ16B,115

Name: Nexperia 16 V 400 mW Zener Diode Single 2-Pin Surface Mount SOD-323 PDZ16B,115
Brand: Nexperia
SKU: 107373
Price: 0.03 USD
Availability: InStock



Category Zener Diodes Brand Nexperia Condition New

Specifications

Country of Origin	China
Brand	Nexperia
Height	1.1mm
Length	2.7mm
Model	PDZ16B,115
Mount Type	Surface
Series	PDZ-B
Maximum Operating Temperature	150°C
Package Type	SOD-323
Standards/Approvals	EU/CN RoHS
Pin Count	2
Number of Elements per Chip	1
Automotive Standard	AEC-Q101
Maximum Power Dissipation Pd	400mW
Diode Configuration	Single
Test Current It	5mA
Maximum Reverse Leakage Current	50nA
Nominal Zener Voltage Vz	16V
Zener Type	Voltage Regulator
Maximum Zener Impedance	20Ω
Typical Voltage Temperature Coefficient	12.4mV/K
Diodes Inc, 24V Zener Diode 2.5% 500 mW SMT 2-Pin SOD-323FBrand	DiodesZetex

Key Features

Nominal Zener voltage of 16 volts with 2% tolerance for precision voltage regulation.
Single element diode configuration designed for stable voltage regulation.
Compact 2-pin SOD-323 surface mount package suitable for automated PCB assembly.
Maximum power dissipation rating of 400 milliwatts ensuring reliable performance.
Meets EU and China RoHS standards and automotive AEC-Q101 qualification for quality assurance.
Maximum operating temperature up to 150 degrees Celsius for durability under demanding conditions.
Low reverse leakage current of 50 nanoamperes minimizing power loss at reverse bias.
Typical zener impedance of 20 ohms and test current of 5 milliamps for effective voltage stabilization.

Product Description

The Nexperia PDZ16B,115 is a single element Zener diode designed for accurate voltage regulation applications. It features a nominal Zener voltage of 16 V with a tolerance of ±2%, ensuring precise voltage stabilization in electronic circuits. Packaged in a small plastic surface-mount SOD-323 (SC-76) package with two pins, it supports compact and automated circuit board assembly.

This diode handles a maximum power dissipation of 400 mW allowing it to perform reliably under moderate power loads. It exhibits a low reverse leakage current of 50 nA, helping to minimize leakage power loss in sensitive applications. With a maximum operating temperature of up to 150°C and compliance with EU/CN RoHS and automotive AEC-Q101 standards, this component is suitable for automotive, industrial, and general electronic use cases.

Its typical voltage temperature coefficient of 12.4 mV/K enhances stable operation across temperature variations. The diode's physical dimensions are 2.7 mm in length and 1.1 mm in height, making it ideal for space-constrained PCB designs. The PDZ-B series component is manufactured in China and optimized for use in power regulation, voltage reference circuitry, and surge protection roles.

Nominal Zener voltage: 16 V with ±2% tolerance. Maximum power dissipation: 400 mW. Surface mount SOD-323 package with 2 pins. Low reverse leakage current: 50 nA. Automotive AEC-Q101 and EU/CN RoHS certified.

This zener diode is widely used in electronic components assemblies in industrial, automotive, and consumer electronics applications. EnvMart offers this component as a reliable solution for voltage regulation needs, supporting diverse manufacturing and design environments.
