Texas Instruments 5-Channel Low Noise LDO Regulator 500 mA 6.5V SOIC 8-Pin TL5209DR

Texas Instruments TL5209DR is a 5-channel Low Dropout (LDO) linear voltage regulator delivering a precise and low noise 6.5V output voltage suitable for various electronic circuits requiring stable power supply management.

This regulator supports an output current of 500 mA with a low quiescent current of 8 mA, facilitating energy-efficient operation. It features excellent line regulation at 0.1%/V and load regulation at 0.7%, ensuring minimal voltage variation under load instead of input changes.

Designed for surface mount application, the device comes in an 8-pin SOIC package measuring 5 mm in length, 4 mm in width, and 1.5 mm in height, allowing for compact integration in PCB designs. It also supports positive polarity and has an adjustable output voltage type, offering flexibility for diverse electrical requirements.

Operating temperature ranges from -40°C to 125°C make it suitable for industrial and harsh environment deployments. The component complies with RoHS standards, ensuring environmentally responsible manufacturing and usage.

Its maximum input voltage is 16V with a minimum input voltage of 2.5V, providing wide supply range compatibility. Its low noise performance makes it ideal for sensitive electronics, communications, and instrumentation applications requiring stable and clean power delivery.

Regulates up to 500 mA output current with a 6.5V adjustable output voltage. Features low quiescent current of 8 mA to maximize power efficiency. Offers 0.1%/V line regulation and 0.7% load regulation for stable operation.

Comes in a compact SOIC 8-pin surface mount package suitable for tight circuit layouts. Operational temperature range from -40°C to 125°C for reliable performance across environments. Pin count of 8 with positive polarity and adjustable output type for flexible design integration.

Maximum input voltage rating of 16V and minimum input voltage of 2.5V. Complies with RoHS environmental standards.

This voltage regulator is ideal for industrial electronics, telecommunications equipment, computing hardware, and other applications requiring multiple regulated outputs with low noise and high precision. It supports robust and efficient power management to enhance system reliability.
