Broadcom DC Input Optocoupler Through Hole 8-Pin DIP HCNW2601-000E
Specifications
| Country of Origin | India |
|---|---|
| Brand | Broadcom |
| Model | HCNW2601-000E |
| Packaging | Tape & Reel |
| Mount Type | Through Hole |
| Series | HCNW |
| Maximum Operating Temperature | 85°C |
| Package Type | DIP |
| Minimum Operating Temperature | -40°C |
| Maximum input current | 20mA |
| Number Of Channels | 1 |
| Standards/Approvals | RoHS, UL, IEC/EN/DIN EN 60747-5-2, CSA |
| Maximum Forward Voltage | 2.05V |
| Number of Pins | 8 |
| Input Current Type | DC |
| Typical Rise Time | 24ns |
| Typical Fall Time | 10ns |
Key Features
- Features a maximum forward voltage of 2.05 volts.
- Operates with direct current input and has a maximum input current of 20 milliamps.
- Typical rise and fall times are 24 nanoseconds and 10 nanoseconds respectively.
- Provides high isolation voltage of 5000 Vrms for enhanced electrical safety.
- Supports operating temperature range from -40°C to 85°C.
- Packaged in tape and reel for automated assembly processes.
- Complies with RoHS, UL, IEC/EN/DIN EN 60747-5-2, and CSA standards.
- Contains one channel with logic output functionality specified in HCNW series.
Product Description
Broadcom HCNW2601-000E is a DC input optocoupler featuring a through hole mount and an 8-pin DIP package type. It offers robust electrical isolation with a high isolation voltage of 5000 Vrms, ensuring protection between input and output circuits. This device functions with a single channel logic output, making it suitable for applications that require signal isolation and switching.
Designed for use in electronic circuits requiring reliable isolation, the optocoupler operates with a maximum forward voltage of 2.05V and a maximum input current of 20mA. The device features fast switching capabilities with typical rise and fall times of 24ns and 10ns respectively, which enhances performance in digital signal applications.
The operating temperature range spans from -40°C to 85°C, allowing it to perform effectively in industrial, commercial, and consumer electronics environments. Packaged in tape and reel, the HCNW2601-000E model is optimized for automated manufacturing processes, improving production efficiency.
Compliance with international standards including RoHS, UL, IEC/EN/DIN EN 60747-5-2, and CSA ensures the component meets safety and environmental requirements for a wide range of electronic systems. However, it is not suited for automotive applications as it does not meet automotive grade certifications.
Maximum forward voltage of 2.05 volts providing efficient current conduction. Logic output channel ideal for signal isolation tasks. High isolation voltage of 5000 Vrms for circuit protection. Thermal operating range from -40°C to 85°C for versatile use.
Fast switching times with 24ns rise time and 10ns fall time. Through hole mount 8-pin DIP package for easy integration. Tape and reel packaging supports automated assembly. Compliant with RoHS, UL, IEC/EN/DIN EN 60747-5-2 and CSA standards.
This Optocoupler is widely applicable in industrial automation, power supplies, signal isolation circuits, and other electronic equipment requiring electrically isolated input/output. It offers reliable performance for manufacturing and laboratory systems. For more products like this, explore the Electronics Components category on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum forward voltage of the HCNW2601-000E is 2.05 volts.
This model has a maximum input current of 20 milliamps.
The typical rise time is 24 nanoseconds, and the typical fall time is 10 nanoseconds.
It offers a high isolation voltage of 5000 Vrms for enhanced electrical safety.
The operating temperature range spans from -40°C to 85°C.
It is packaged in tape and reel for automated assembly processes.
This model features a through hole mount type.
The HCNW2601-000E has one channel with logic output functionality.
It complies with RoHS, UL, IEC/EN/DIN EN 60747-5-2, and CSA standards.
The package type is an 8-pin DIP.
It is widely applicable in industrial automation, power supplies, and signal isolation circuits.
The HCNW2601-000E operates with direct current (DC) input.
