onsemi Zener Diode Single 10 V 500 mW Surface Mount 2-Pin SOD-123 MMSZ4697T1G

Free Delivery in India | Lowest Global Shipping Charges

onsemi Zener Diode Single 10 V 500 mW Surface Mount 2-Pin SOD-123 MMSZ4697T1G

Name: onsemi Zener Diode Single 10 V 500 mW Surface Mount 2-Pin SOD-123 MMSZ4697T1G
Brand: onsemi
SKU: 106353
Price: 0.03 USD
Availability: InStock



Category Zener Diodes Brand onsemi Condition New

Specifications

Country of Origin	India
Brand	onsemi
Height	1.35mm
Length	2.84mm
Model	MMSZ4697T1G
Mount Type	Surface
Series	MMS
Maximum Operating Temperature	150°C
Package Type	SOD-123
Minimum Operating Temperature	-55°C
Pin Count	2
Number of Elements per Chip	1
Automotive Standard	AEC-Q101
Maximum Power Dissipation Pd	500mW
Diode Configuration	Single
Test Current It	0.05mA
Maximum Reverse Leakage Current	1μA
Nominal Zener Voltage Vz	10V
Zener Type	Voltage Regulator
Surface Mount case	SOD-123

Key Features

Single diode configuration designed for voltage regulation applications.
Surface mount mount type with a compact 2-pin SOD-123 package.
Maximum power dissipation rating of 500 mW for stable performance.
Operating temperature range from -55°C to 150°C for reliability.
Typical test current of 0.05 mA with a maximum reverse leakage current of 1 μA.
Zener voltage tolerance of ±5% ensuring precision voltage regulation.
Complies with automotive standard AEC-Q101, suitable for automotive electronics use.

Product Description

onsemi MMSZ4697T1G is a voltage regulator Zener diode designed for discrete semiconductor applications requiring precise voltage regulation. It is configured as a single diode housed in a surface mount SOD-123 package featuring a compact 2-pin design.

This Zener diode supports a nominal Zener voltage of 10 V and can dissipate up to 500 mW of power, making it suitable for moderate power applications. The device maintains excellent performance across a wide operating temperature range of -55°C to 150°C, ensuring reliability in harsh industrial, automotive, and electronic environments.

Featuring a Zener voltage tolerance of ±5% and a typical test current of 0.05 mA, the MMSZ4697T1G diode ensures consistent voltage regulation. Its low maximum reverse leakage current of 1 μA helps maintain efficiency and reduces potential leakage losses.

The compact dimensions of 1.35 mm height and 2.84 mm length enable integration into densely packed printed circuit boards. Compliance with the AEC-Q101 automotive standard confirms its suitability for automotive electronics, including sensor circuits and power regulation modules.

Single diode configuration designed for voltage regulation applications. Surface mount SOD-123 package with 2 pins for easy PCB assembly. Power rating of 500 mW suitable for moderate power control applications. Operating temperature range from -55°C to 150°C supports industrial usage.

Zener voltage tolerance of ±5% for precise voltage regulation. Low reverse leakage current maximizes efficiency. Meets automotive qualification standard AEC-Q101.

This product is ideal for industrial, automotive, telecommunications, and consumer electronics applications requiring stable voltage regulation in compact SMT packages. It is suited for use in power supply circuits, voltage reference designs, and circuit protection schemes.

Explore more voltage regulator solutions and semiconductor components at EnvMart for robust and reliable electronic component sourcing.

Explore more products in our Zener Diodes category.
