Samtec TSW Series Straight Through Hole Pin Header 14 Contacts 2.54 mm Pitch 2 Row Unshrouded TSW-107-05-T-D
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 550V |
| Brand | Samtec |
| Orientation | Straight |
| Model | TSW-107-05-T-D |
| Mount Type | Through Hole |
| Housing Material | Glass Filled Polyester |
| Contact Material | Phosphor Bronze |
| Series | TSW |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 14 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Operating temp range | -55 °C to +125 °C with Gold -55 °C to +105 °C with Tin |
| Plating used | Au or Sn over 50 μ" (1.27 μm) Ni |
Key Features
- Constructed with black glass filled polyester housing for durability.
- Contacts are made of phosphor bronze with gold plating for excellent conductivity.
- Supports operating temperature range from -55°C to +125°C with gold plating.
- Rated for voltage up to 550V, ideal for various electronic component assemblies.
- Through-hole mount type ensures robust mechanical and electrical connection.
- Unshrouded design allows easy access to contacts during soldering.
- Compatible with solder termination and male contact gender.
- Designed for industrial electronics and PCB header applications.
Product Description
Samtec TSW-107-05-T-D is a high-quality pin header from the TSW series designed for board-to-board connections. Featuring 14 gold-plated phosphor bronze contacts arranged in 2 rows with a 2.54 mm pitch, this straight through-hole pin header provides reliable electrical performance for industrial, electronics manufacturing, and assembly applications.
The connector housing is crafted from black glass filled polyester, ensuring mechanical stability and durability under operating conditions. The contact plating utilizes gold or tin over a 50 μ" (1.27 μm) nickel base, providing corrosion resistance and excellent conductivity.
Operating temperature ranges from -55 °C to +125 °C for gold-plated contacts and -55 °C to +105 °C for tin-plated contacts, supporting a wide variety of electronic system environments. The component supports a maximum voltage rating of up to 550V when mated appropriately.
This unshrouded, through-hole mount pin header is intended for solder termination and features male contact gender, suitable for robust board connections. It is RoHS compliant and does not carry specific certifications or approvals.
Black glass filled polyester housing for durability. Phosphor bronze contacts with gold plating for conductivity and corrosion resistance. Operating temperature tolerance from -55°C to +125°C. Voltage rating up to 550 volts suitable for electronic assemblies.
Through-hole mounting for secure PCB installation. Unshrouded straight orientation for easy access and soldering. Compatible with board-to-board connector systems. Ideal for industrial electronics, manufacturing, and PCB header applications.
This Samtec Pin Header is a key component for PCB assemblies requiring reliable electrically conductive connections. It blends robust materials with proven design, making it suitable for industrial, electronic component manufacturing, and various assembly lines.
Explore more electronic components and PCB headers from trusted brands at EnvMart to complete your assembly and manufacturing needs.
Explore more products in our PCB Pin Header category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a maximum voltage rating of up to 550V when mated appropriately.
The contacts are made of phosphor bronze and feature gold plating for excellent conductivity and corrosion resistance.
The gold-plated contacts support an operating temperature range from -55°C to +125°C.
This pin header features 14 contacts arranged in 2 rows.
It uses a through-hole mount type, ensuring a secure mechanical and electrical connection.
Yes, it is designed for solder termination and features male contact gender.
The contacts are arranged with a pitch of 2.54 mm.
The housing is constructed from black glass filled polyester, providing mechanical stability.
This model features a straight orientation, which allows easy access to contacts during soldering.
It is designed for board-to-board connector systems, making it suitable for various electronic applications.
This pin header is RoHS compliant, ensuring it meets environmental regulations.
The country of origin for this product is India.
