Samtec TST Series Right Angle Through Hole PCB Header, 10 Contacts, 2.54 mm Pitch, 2 Row, Shrouded TST-105-04-T-D-RA
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 425V |
| Brand | Samtec |
| Orientation | Right Angle |
| Current | 3.4A |
| Model | TST-105-04-T-D-RA |
| Mount Type | Through Hole |
| Housing Material | Glass Filled Polyester |
| Contact Material | Phosphor Bronze |
| Series | TST |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Plating | Au or Sn over 50 μ" (1.27 μm) Ni |
| Pitch | 2.54mm |
| Contact Plating | Gold or Tin |
| Number of Contacts | 10 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Board-to-Cable |
| Current rating (IDSD/TST) | 3.4 A per pin (2 pins powered) |
Key Features
- Constructed with black glass filled polyester housing for durability.
- Phosphor bronze contacts plated with gold or tin for reliable connectivity.
- Rated for up to 3.4 A current per pin with 2 pins powered.
- Operates within temperature range of -55°C to 125°C depending on plating.
- Right angle, through hole mount design ensures secure board connection.
- Meets UL 94V-0 flammability rating and RoHS compliant for safety and environmental standards.
- Ideal for electronic, industrial and manufacturing PCB connector applications.
Product Description
Samtec TST-105-04-T-D-RA is a high-quality Right Angle Through Hole PCB Header designed for use in electronic and industrial applications. Featuring 10 male contacts arranged in 2 rows with a standard 2.54 mm pitch, this PCB header ensures a reliable and secure board-to-cable connection.
The housing is made from durable black glass filled polyester material, providing mechanical strength and resistance to environmental factors. The contacts are fabricated from phosphor bronze and plated with either gold or tin over 50 μ" (1.27 μm) nickel, offering excellent electrical conductivity and corrosion resistance.
This connector supports a current rating of 3.4 A per pin when 2 pins are powered and can operate across a wide temperature range from -55°C to 125°C (depending on plating). It is rated for voltages up to 425 V AC/600 V DC and complies with UL 94V-0 flammability standards, ensuring safety and reliability in demanding applications.
The right angle orientation and through hole mount type make it suitable for secure PCB installation, enhancing design flexibility in electronic assemblies and manufacturing environments.
Black glass filled polyester housing for mechanical and environmental durability. Phosphor bronze male contacts plated with gold or tin for superior electrical performance. Rated for 3.4 A per pin and capable of handling 425 V AC/600 V DC.
Wide operating temperature range from -55°C to 125°C for varied environments. Shrouded design offers added protection and connector integrity. Compliance with UL 94V-0 flammability and RoHS directives for safety and eco-friendliness.
Ideal for industrial, commercial, laboratory, manufacturing, and electronics applications requiring reliable PCB connectors.
This Samtec TST Series PCB Header provides a robust and dependable solution for board-to-cable connections in industrial and electronic assembly scenarios. Explore additional electronic components and connectors in the Electronics & Electricals category at EnvMart for complementary products.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model is rated for up to 3.4 A per pin when 2 pins are powered.
It is rated for voltages up to 425 V AC and 600 V DC.
The contacts are arranged with a standard pitch of 2.54 mm.
The housing is made from black glass filled polyester, and the contacts are phosphor bronze plated with either gold or tin.
It operates within a temperature range of -55°C to 125°C, depending on the plating.
This unit features 10 male contacts arranged in 2 rows.
It uses a through hole mount design for secure board connection.
Yes, it meets the UL 94V-0 flammability rating and is RoHS compliant.
The termination type for this model is solder.
The contacts are oriented in a right angle configuration.
It is ideal for electronic, industrial, and manufacturing PCB connector applications.
The contacts are plated with either gold or tin over 50 μ" (1.27 μm) nickel.
