Samtec SSQ Series Right Angle Through Hole PCB Socket, 8-Contact, 1 Row, 2.54 mm Pitch, Solder Termination SSQ-108-02-T-S-RA
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 655V |
| Brand | Samtec |
| Orientation | Right Angle |
| Current | 6.3A |
| Model | SSQ-108-02-T-S-RA |
| Mount Type | Through Hole |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Current Rating | 6.3A per pin(2 pins powered) |
| Series | SSQ |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Sub Type | Square Tail |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Max Cycles | 100 with 10μ"(0.25μm) Au |
| Pitch | 2.54mm |
| Contact Plating | Tin |
| Number of Contacts | 8 |
| Contact Gender | Female |
| Connector System | Board-to-Board |
Key Features
- Constructed with a liquid crystal polymer housing for durability and insulation.
- Phosphor bronze contact material ensures reliable conductivity.
- Right angle orientation facilitates efficient PCB layout.
- Rated for 6.3A current per pin with 2 pins powered.
- Supports operating temperatures from -55°C to 105°C for varied environments.
- Features tin plating on contacts to ensure solderability and corrosion resistance.
- Designed with a Tiger Buy™ contact system offering stable normal force of 125 grams.
- Maximum cycles of 100 with 0.25 μm gold plating for extended durability.
Product Description
Samtec SSQ-108-02-T-S-RA is a high-quality, right angle through hole PCB socket designed for reliable board-to-board connections in electronic assemblies. This socket features 8 contacts arranged in a single row with a standard 2.54 mm pitch, making it suitable for precise PCB configurations and efficient space usage.
The housing is made from liquid crystal polymer, providing excellent mechanical strength and electrical insulation properties. Contacts are manufactured from phosphor bronze, known for its excellent conductivity and spring properties, and are plated with tin to ensure reliable solder termination and corrosion resistance.
Operating under demanding industrial and commercial environments, this PCB socket maintains functionality across a wide temperature range from -55°C to 105°C. The Tiger Buy™ contact system provides a standard normal force of 125 grams, ensuring consistent pin engagement and electrical contact, with a lifecycle of up to 100 mating cycles under a 0.25 μm gold plating.
The electrical specifications include a current rating of 6.3 amps per pin when two pins are powered and a voltage rating of 465VAC/655VDC, enabling the socket to perform safely under high electrical stresses.
This product is ideal for use in electronics manufacturing, repair, prototyping, and industrial control applications requiring reliable and durable PCB connectors. Liquid crystal polymer housing for durability and electrical performance.
Phosphor bronze contacts with tin plating for excellent conductivity and solderability. Right angle orientation to optimize PCB layout and connectivity. Rated for 6.3 A current per pin with high voltage tolerance. Wide operating temperature range suitable for industrial environments.
Tiger Buy™ contact system ensures stable normal force and durability. Maximum mating cycles of 100 with gold plating longevity. Explore the full range of high-performance PCB Sockets and connectors from Samtec and related electronic components on EnvMart for dependable assembly and maintenance solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a current rating of 6.3A per pin when two pins are powered.
The maximum operating temperature for this socket is 105°C.
It features a housing made of liquid crystal polymer and contacts made from phosphor bronze with tin plating.
The SSQ-108-02-T-S-RA has a total of 8 contacts arranged in a single row.
The pitch of the contacts in this PCB socket is 2.54 mm.
This model is rated for a voltage of 655V.
The SSQ-108-02-T-S-RA features a right angle orientation, which facilitates efficient PCB layout.
It is designed for a maximum of 100 mating cycles with 0.25 μm gold plating.
This PCB socket uses solder termination for reliable connections.
The minimum operating temperature for the SSQ-108-02-T-S-RA is -55°C.
It supports a board-to-board connector system, making it suitable for reliable connections in electronic assemblies.
The contact gender for this model is female.
