Samtec CLE Series Vertical Surface PCB Socket, 5-Contact, 2 Row Press-in CLE-105-01-G-DV-TR

Samtec CLE-105-01-G-DV-TR is a vertical surface mount PCB socket designed with 5 contacts in 2 rows and press-in termination. The socket housing is manufactured from LCP material offering robust mechanical and thermal stability suitable for demanding electronic applications.

Featuring gold-plated contacts, this socket ensures excellent electrical conductivity and corrosion resistance, making it ideal for high-reliability circuits. Its vertical orientation and surface mount design simplify assembly on printed circuit boards.

The socket operates within a broad temperature range from -55°C to 125°C, making it suitable for industrial, laboratory, manufacturing, and electronic device applications that require stable performance under varying environmental conditions.

Part of the CLE series, this 0.80 mm pitch Tiger beam socket strip supports positions up to 180, providing scalability for different PCB designs. Cost-saving gold plating and optional tape and reel packaging offer value for high-volume production environments.

Constructed with an LCP housing material ensuring durability. Contact plating is gold for enhanced conductivity and corrosion resistance. Designed for vertical orientation with surface mount type for ease of installation.

Operates reliably within -55°C to 125°C temperature range. Series CLE socket supports up to 180 positions for flexible application. RoHS compliant meeting environmental and safety regulations. Available with optional tape and reel packaging for automated assembly.

The 0.80 mm Tiger beam provides cost-effective single beam socket strip design.

This Samtec PCB Socket is suitable for a wide range of electronics including industrial control systems, communication devices, computing hardware, and test instruments. Its combination of mechanical strength, electrical performance, and compliance makes it a reliable choice for professional electronic manufacturing and repair.
