Wurth Elektronik WE-PD 1260 Shielded Wirewound Surface Mount Inductor 33μH ±20% 2.68A IDC 744771133
Specifications
| Country of Origin | India |
|---|---|
| Diameter | 8mm |
| Brand | Wurth Elektronik |
| Height | 6mm |
| Length | 12mm |
| Depth | 12mm |
| Packaging | Tape & Reel |
| Series | WE-PD |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 33μH |
| Standards/Approvals | RoHS, REACH |
| Package/Case | 1260 |
| Maximum DC Current | 2.68A |
| Pin Count | 2 |
| Maximum DC Resistance | 57mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 11MHz |
| Inductor Construction | Wirewound |
| Automotive Standard | AEC-Q200 |
| Recommended solder profile | Reflow |
Key Features
- 33 microhenry inductance with a tolerance of plus or minus 20 percent.
- Maximum DC current rating is 2.68 amperes.
- Package size 1260 with dimensions 12 mm length, 8 mm diameter, and 6 mm height.
- Features magnetic shielding to minimize leakage fields and low self-losses.
- Suitable for switching regulators and integrated DC/DC converters operating between -40°C and 125°C.
- Meets automotive standard AEC-Q200 and complies with RoHS and REACH directives.
- Recommended solder profile is reflow suitable for surface mount technology.
- Maximum DC resistance is 57 milliohms ensuring efficiency.
Product Description
Wurth Elektronik model 744771133 is a WE-PD 1260 series shielded wirewound surface mount inductor featuring a ferrite core with a nominal inductance of 33 microhenries and a tolerance of ±20%. It is designed to handle a maximum DC current of 2.68 amperes, making it suitable for applications requiring high current handling in compact SMD form factors.
This surface mount inductor has physical dimensions of 12 mm length, 8 mm diameter, and 6 mm height, packaged in a 1260 case style, optimized for tape and reel delivery, enhancing manufacturing efficiency for automated PCB assembly.
Its magnetically shielded design minimizes leakage magnetic fields, providing high storage capacity with low self-losses. The component operates reliably within a temperature range of -40°C to +125°C, meeting the stringent AEC-Q200 automotive standard. The inductor construction uses a ferrite core and wirewound techniques, molded to ensure mechanical stability.
With a maximum DC resistance of 57 milliohms and a maximum self-resonant frequency of 11 MHz, it supports switching regulators, integrated DC/DC converters, and applications requiring efficient high-frequency performance such as graphic cards and other power electronics.
33 μH inductance with ±20% tolerance. Maximum DC current 2.68 A. Package/Case 1260, length 12 mm, diameter 8 mm, height 6 mm. Shielded design reduces leakage fields. Automotive standard AEC-Q200 compliant. Operating temperature from -40°C to 125°C.
RoHS and REACH compliant. Recommended reflow solder profile. Maximum DC resistance 57 mΩ. Maximum self-resonant frequency 11 MHz.
This shielded wirewound surface mount inductor is ideal for industrial, automotive, and commercial electronics requiring reliable high current inductors in compact sizes. Whether used in switching power supplies or integrated circuits, it balances efficiency and durability.
Explore more Surface Mount Inductors and electronic components at EnvMart for quality and performance-assured parts.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a nominal inductance of 33 microhenries (μH) with a tolerance of ±20%.
The maximum DC current rating for this unit is 2.68 amperes.
It has dimensions of 12 mm in length, 8 mm in diameter, and 6 mm in height.
The inductor can operate at a maximum temperature of 125°C.
Yes, it meets the automotive standard AEC-Q200 and complies with RoHS and REACH directives.
This surface mount inductor features a ferrite core material.
The recommended solder profile for this model is reflow, suitable for surface mount technology.
The maximum DC resistance is 57 milliohms (mΩ).
The maximum self-resonant frequency is 11 MHz.
It is suitable for switching regulators and integrated DC/DC converters, as well as applications requiring high-frequency performance.
This inductor is packaged in a tape and reel style, which enhances manufacturing efficiency for automated PCB assembly.
The inductor is constructed using wirewound techniques, ensuring mechanical stability.
