Wurth Elektronik WE-TPC 2828 Shielded Wirewound Surface Mount Inductor Ferrite Core 4.7μH ±20 % 1.35A DC 125°C 744025004
Specifications
| Country of Origin | India |
|---|---|
| Brand | Wurth Elektronik |
| Operating Temperature | - 40 to +125°C |
| Height | 2.8mm |
| Length | 2.8mm |
| Depth | 2.8mm |
| Packaging | Tape & Reel |
| Series | WE-TPC |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 4.7μH |
| Package/Case | 2828 |
| Maximum DC Current | 1.35A |
| Pin Count | 2 |
| Maximum DC Resistance | 120mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 84MHz |
| Inductor Construction | Wirewound |
| IEC 61249-2-21, RoHS, REACH, JEDEC JS709B, IPC/JEDEC J-STD-020E, IEC 60286-3 | 2013 |
Key Features
- Compact 2.8mm x 2.8mm package suitable for high-density PCB mounting.
- Magnetically shielded design provides low leakage magnetic field for sensitive applications.
- Maximum operating temperature of 125°C supports robust industrial and automotive environments.
- Moulded wirewound construction enhances reliability and performance.
- Compliance with IEC 61249-2-21, RoHS, REACH, JEDEC, and IPC/JEDEC standards ensures quality and environmental safety.
- Tape & reel packaging facilitates automated assembly processes.
- Maximum self-resonant frequency of 84MHz supports high-frequency power applications.
- Wide operating temperature range from -40°C to +125°C for diverse environments.
Product Description
Wurth Elektronik 744025004 is a 2828 series shielded wirewound Surface Mount Inductor featuring a ferrite core with an inductance of 4.7μH and tolerance of ±20%. This compact inductor has a maximum DC current rating of 1.35A and operates efficiently up to temperatures of 125°C. It is designed for use in high density electronic circuits requiring stable inductance and low magnetic leakage.
The WE-TPC 2828 series is highly regarded for its extremely flat power inductors with high current handling capability and magnetically shielded design, which minimizes the magnetic leakage field. Its wirewound construction combined with a moulded ferrite core ensures enhanced reliability and robust performance under varying environmental conditions.
This inductor meets industry standards including IEC 61249-2-21, RoHS, REACH, JEDEC JS709B, IPC/JEDEC J-STD-020E, and IEC 60286-3:2013, making it suitable for industrial, automotive, telecommunications, and portable power applications such as PDAs, digital cameras, PCMCIA cards, DC/DC converters, embedded PC systems, and mobile data gathering devices.
The surface mount termination style and tape & reel packaging enable efficient automated assembly for mass production. With a maximum self-resonant frequency of 84MHz, it supports a wide bandwidth including RF and power electronics.
Physical dimensions are 2.8mm length, 2.8mm width, and 2.8mm height with 2 pins for mounting. The device is moulded and magnetically shielded, with a maximum DC resistance of 120mΩ. Operating temperature ranges from -40°C to +125°C, ensuring stable operation in harsh environments.
Compact 2.8mm square shielded wirewound inductor. High current capability up to 1.35A DC. Magnetically shielded design for low leakage fields. Robust operation from -40°C to +125°C. Compliance with key international standards including RoHS and REACH.
Tape and reel packaging suitable for automated SMT assembly.
Wurth Elektronik inductors are widely trusted in industries such as electronics manufacturing, telecommunications, automotive electronics, and instrumentation. This model 744025004 provides a balance of size, performance, and reliability for demanding surface mount power and signal applications. Browse more high quality inductors and Wurth Elektronik products at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this model is 4.7μH with a tolerance of ±20%.
It has a maximum DC current rating of 1.35A.
The dimensions are 2.8mm in length, width, and height, making it a compact package suitable for high-density PCB mounting.
The maximum operating temperature is 125°C, allowing it to function in robust industrial and automotive environments.
The minimum operating temperature is -40°C, enabling stable operation in harsh environments.
The maximum self-resonant frequency is 84MHz, supporting high-frequency power applications.
This inductor features a ferrite core, which enhances its performance and reliability.
It complies with IEC 61249-2-21, RoHS, REACH, JEDEC JS709B, IPC/JEDEC J-STD-020E, and IEC 60286-3:2013 standards.
It is packaged in tape and reel format, which facilitates automated assembly processes.
The termination style is surface mount, suitable for high-density electronic circuits.
This model has 2 pins for mounting.
The maximum DC resistance is 120mΩ, which contributes to its efficiency.
