Wurth Elektronik Wirewound Surface Mount Inductor 100 μH ±10 % 800 mA Idc Ferrite Core WE-TI 5075 7447462101
Specifications
| Country of Origin | China |
|---|---|
| Diameter | 6mm |
| Brand | Wurth Elektronik |
| Height | 8.5mm |
| Length | 6mm |
| Depth | 6mm |
| Packaging | Bag and Carton |
| Series | WE-TI |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 100μH |
| Standards/Approvals | IEC 61249-2-21, JEDEC JS709B, RoHS, REACH |
| Package/Case | 5075 |
| Maximum DC Current | 800mA |
| Pin Count | 2 |
| Maximum DC Resistance | 650mΩ |
| Inductance Tolerance | ±10 % |
| Termination Style | Radial |
| Maximum Self Resonant Frequency | 7.1MHz |
| Inductor Construction | Wirewound |
Key Features
- The WE-TI 5075 package provides a compact size of 6 mm diameter and 8.5 mm height.
- Constructed with a high-quality ferrite core and wirewound design for reliable performance.
- Features 650 mΩ maximum DC resistance and operates between -40°C to 125°C.
- Non-shielded inductor suitable for signal filtering, decoupling, and EMI suppression.
- Maximum self-resonant frequency of 7.1 MHz supports high-frequency applications.
- Radial termination style and 2 pins for secure mounting.
- Designed for power supply filters and low power switch mode regulators.
- Complies with IEC 61249-2-21, JEDEC JS709B, RoHS, and REACH standards.
Product Description
Wurth Elektronik 7447462101 wirewound surface mount inductor WE-TI 5075 is a compact and high-quality passive electronic component characterized by a 100 μH ±10 % inductance with 800 mA maximum DC current rating. It features a ferrite core wirewound construction offering stable inductance and low losses in diverse industrial and commercial electronic applications.
This radial leaded inductor design measures 6 mm in diameter and 8.5 mm in height, fitting small form-factor circuit boards efficiently. Its maximum DC resistance of 650 mΩ ensures minimal power loss, while the non-shielded ferrite core provides effective magnetic properties for signal filtering, EMI suppression, and power supply noise reduction.
The component reliably operates in a temperature range from -40°C to 125°C making it suitable for harsh conditions in telecommunications, industrial controllers, and automotive electronics (non-automotive certified). Its self-resonant frequency of 7.1 MHz supports use in high-frequency filter circuits and switching regulators.
With two radial pins for secure PCB mounting, this inductor comes packaged in bags and cartons optimized for efficient manufacturing insertion. It complies with IEC 61249-2-21, JEDEC JS709B, as well as RoHS and REACH directives ensuring environmental and safety standards compliance.
The WE-TI 5075 inductor is ideal for signal filtering, decoupling tasks, and EMI filtering in power supplies and switch mode regulators. Its wirewound ferrite core construction enhances performance stability across electrical and thermal stress.
The product offers a compact size fit for densely packed circuit boards without compromise on electrical characteristics. Designed for use in industrial, commercial, and consumer electronics requiring reliable surface mount inductors.
Explore more Surface Mount Inductors and electronic components in EnvMart's extensive catalog for your engineering and manufacturing needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has an inductance value of 100 μH with a tolerance of ±10%.
The maximum DC current rating for this inductor is 800 mA.
It has a diameter of 6 mm and a height of 8.5 mm.
The maximum DC resistance is 650 mΩ.
It operates within a temperature range of -40°C to 125°C.
The maximum self-resonant frequency is 7.1 MHz, suitable for high-frequency applications.
The inductor is constructed with a ferrite core.
It features a radial termination style with 2 pins for secure mounting.
It complies with IEC 61249-2-21, JEDEC JS709B, RoHS, and REACH standards.
This inductor is packaged in bags and cartons optimized for efficient manufacturing insertion.
It is suitable for signal filtering, decoupling, and EMI suppression in power supplies and low power switch mode regulators.
This inductor belongs to the WE-TI series.
