Murata Ferrite Bead 0.85 mm Surface Mount 0805 Chip Ferrite Bead 60 Ω Impedance at 100 MHz BLM21PG600SN1D

Free Delivery in India | Lowest Global Shipping Charges

Murata Ferrite Bead 0.85 mm Surface Mount 0805 Chip Ferrite Bead 60 Ω Impedance at 100 MHz BLM21PG600SN1D

Name: Murata Ferrite Bead 0.85 mm Surface Mount 0805 Chip Ferrite Bead 60 Ω Impedance at 100 MHz BLM21PG600SN1D
Brand: Murata
SKU: 103484
Price: 0.07 USD
Availability: InStock



Category Ferrite Bead Brand Murata Condition New

Specifications

Country of Origin	Japan
Brand	Murata
Material	Ferrite
Height	0.85mm
Length	2mm
Model	BLM21PG600SN1D
Depth	1.25mm
Packaging	Tape & Reel
Mount Type	Surface
Current Rating	3.5A
Series	BLM21PG
Maximum Operating Temperature	125°C
Package Type	0805
Sub Type	Chip Ferrite Bead
Minimum Operating Temperature	-55°C
Standards/Approvals	RoHS, REACH
Pin Count	1
Maximum DC Resistance	20mΩ
Impedance at 100 MHz	60Ω
Murata Ferrite Bead (Chip Ferrite Bead), 2 x 1.25 x 0.85mmBrand	Murata

Key Features

This chip ferrite bead features a compact 0805 package size suitable for surface mounting.
It supports a maximum current rating of 3.5 A for high current circuit applications.
The bead operates reliably in a temperature range from -55°C to 125°C.
The nickel barrier construction provides excellent solder heat resistance and durability.
It has low DC resistance, only 20 mΩ, minimizing voltage loss in high current circuits.
Constructed with ferrite material optimized for EMI noise reduction on power supply lines.
The physical dimensions measure approximately 2 mm length, 1.25 mm depth, and 0.85 mm height.
Suitable for industrial, electronic, and power supply EMI filtering applications.

Product Description

Murata BLM21PG600SN1D ferrite bead is a surface mount device in 0805 size, specifically engineered for EMI noise suppression in electronic circuits. It provides an impedance of 60 Ω at 100 MHz which is ideal for stabilizing unstable ground lines without distortion of signal waveforms.

The chip ferrite bead supports up to 3.5 A current and operates safely between -55°C and 125°C, making it suitable for harsh industrial and electronic environments. The nickel barrier construction on external electrodes offers excellent resistance to soldering heat, ensuring durability and reliable connections.

The bead's low DC resistance of 20 mΩ helps reduce power losses in high current circuits, enhancing overall circuit efficiency. Its compact dimensions of 2 mm length, 1.25 mm depth, and 0.85 mm height allow for space-saving surface mount configurations in PCBs.

Constructed from ferrite material, this bead effectively filters EMI noise and is ideal for use in power supplies, EMI suppression filters, and general electronic circuit applications. Manufactured in Japan, it conforms to RoHS and REACH environmental standards.

This chip ferrite bead features a compact 0805 package size suitable for surface mounting. It supports a maximum current rating of 3.5 A for high current circuit applications. The bead operates reliably in a temperature range from -55°C to 125°C.

The nickel barrier construction provides excellent solder heat resistance and durability. It has low DC resistance, only 20 mΩ, minimizing voltage loss in high current circuits. Constructed with ferrite material optimized for EMI noise reduction on power supply lines.

The physical dimensions measure approximately 2 mm length, 1.25 mm depth, and 0.85 mm height. Suitable for industrial, electronic, and power supply EMI filtering applications. Manufactured in Japan with compliance to RoHS and REACH standards.

This Murata Ferrite Bead is recommended for use in industrial manufacturing, electronics assembly, power electronics, and laboratory instrumentation where reliable EMI suppression is critical. Explore more electronic components and EMI filtering solutions in the Electronics Components category at EnvMart.
