Wurth Elektronik 4124M Series PCB Terminal Block, 3-Contact, 7.62 mm Pitch, Through Hole Mount, Grey, 750V ac 691412420003M
Specifications
| Country of Origin | Italy |
|---|---|
| Voltage | 750V ac |
| Brand | Wurth Elektronik |
| Colour | Grey |
| Orientation | 45° |
| Current | 4A |
| Length | 20.55mm |
| Model | 691412420003M |
| Depth | 13.2mm |
| Width | 12mm |
| Mount Type | Through Hole |
| Series | 4124M |
| Number of Rows | 1 |
| Pitch | 7.62mm |
| Standards/Approvals | VDE, cULus, RoHS |
| Number of Contacts | 3 |
| Minimum Wire Size mm² | 0.05mm² |
| Maximum Wire Size mm² | 1.3mm² |
| Minimum Wire Size AWG | 30AWG |
| Maximum Wire Size AWG | 16AWG |
Key Features
- Features a single row configuration with 3 contacts for easy PCB integration.
- Operates at a voltage rating of 750V AC and current rating of 4A.
- Constructed with grey color housing and oriented at 45 degrees for flexible mounting.
- Accommodates wire sizes from 30 AWG up to 16 AWG (0.05 mm² to 1.3 mm²).
- Compact size with dimensions 20.55 mm length, 12 mm width, and 13.2 mm depth.
- Mounts securely using through hole technology ensuring reliable electrical connection.
- Complies with standards including VDE, cULus, and RoHS for quality and safety.
- Manufactured in Italy with robust industrial design for durability.
Product Description
Wurth Elektronik 691412420003M PCB Terminal Block is a high-quality component engineered for secure and efficient electrical connections on printed circuit boards. Featuring 3 contacts arranged in a single row, this terminal block operates at 750V AC and 4A current, making it suitable for various industrial electronic applications.
The terminal block utilizes a 7.62 mm pitch and is oriented at a 45° angle to facilitate compact and flexible PCB layouts. Its grey-colored housing provides robust insulation and protection with a compact footprint measuring 20.55 mm in length, 12 mm in width, and 13.2 mm in depth. It supports wires ranging from 30 AWG (0.05 mm²) to 16 AWG (1.3 mm²), accommodating a range of conductor sizes for diverse wiring needs.
Designed for through-hole mounting, this component ensures strong mechanical and electrical connections on PCBs. It is compliant with key safety and quality certifications including VDE, cULus, and RoHS, affirming its reliability and environmental safety standards.
Manufactured in Italy, the Wurth Elektronik 4124M Series terminal blocks are developed with precision to meet the requirements of industrial electronics, control systems, and power distribution equipment. Their modular design allows for scalable configurations to suit different application demands in electronics manufacturing, automotive, and automation industries.
Features a single row of 3 contacts with 7.62 mm pitch for efficient PCB assembly. Rated for voltage up to 750V AC and current up to 4A for moderate power circuits. Supports wire sizes between 30 AWG and 16 AWG to cover a wide range of conductor thickness.
Durable through-hole mount design for strong and reliable electrical connectivity. Meets RoHS, VDE, and cULus certifications for safety and environmental compliance. Compact dimensions enhance design flexibility in electronic circuit boards.
Grey insulation housing offers mechanical protection and ease of installation. Ideal for use in industrial electronics, control panels, and power supplies.
Explore more PCB Terminal Blocks from Wurth Elektronik in our Electronics Components category for versatile connector solutions suited to various industrial and manufacturing applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It operates at a voltage rating of 750V AC.
The current rating is 4A.
It accommodates wire sizes from 30 AWG (0.05 mm²) to 16 AWG (1.3 mm²).
The dimensions are 20.55 mm in length, 12 mm in width, and 13.2 mm in depth.
The pitch of the contacts is 7.62 mm.
It features 3 contacts arranged in a single row configuration.
It uses through hole mounting for secure installation on PCBs.
It is oriented at a 45° angle to facilitate flexible mounting.
It complies with VDE, cULus, and RoHS standards for safety and environmental compliance.
It is manufactured in Italy.
The housing is grey in color, providing insulation and protection.
It is suitable for various industrial electronic applications, including control systems and power distribution equipment.
