Wurth Elektronik 2196 Series 2-Contact PCB Terminal Block, 10.16 mm Pitch, Through Hole, 1 Row 691219610002
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 300V ac |
| Brand | Wurth Elektronik |
| Colour | Grey |
| Orientation | Horizontal |
| Current | 57A |
| Length | 20.92mm |
| Depth | 28.5mm |
| Width | 18.3mm |
| Mount Type | Through Hole |
| Series | 2196 |
| Number of Rows | 1 |
| Pitch | 10.16mm |
| Standards/Approvals | VDE, RoHS, cULus |
| Number of Contacts | 2 |
| Minimum Wire Size mm² | 0.3mm² |
| Maximum Wire Size mm² | 8.3mm² |
| Minimum Wire Size AWG | 22AWG |
| Maximum Wire Size AWG | 8AWG |
Key Features
- Supports 57A current rating for robust performance.
- Designed for through hole mount with one row of contacts.
- Suitable for wire sizes from 0.3 mm² to 8.3 mm² (22AWG to 8AWG).
- Operates safely at up to 300V AC voltage rating.
- Equipped with standard 10.16 mm pitch and 18.3 mm width.
- Constructed with grey color housing and compliant with VDE, RoHS, and cULus standards.
Product Description
Wurth Elektronik 691219610002 PCB Terminal Block is a high-quality electronic component designed for industrial and electrical applications requiring secure and efficient PCB connection solutions. This model features two contacts arranged in a single row with a standard 10.16 mm pitch, suitable for soldering via through hole mounting on printed circuit boards.
Engineered to carry currents up to 57 amperes, it supports a wide range of wire sizes from 0.3 mm² up to 8.3 mm², accommodating AWG sizes 22 to 8. The product’s horizontal orientation and grey color provide versatility and standardization for custom electrical designs.
The terminal block operates safely at voltages up to 300V AC, making it well-suited for power distribution, control panels, and other industrial or commercial electrical assemblies. It complies with international standards including VDE, RoHS, and cULus, ensuring quality and regulatory compliance.
The compact dimensions - 20.92 mm length, 18.3 mm width, and 28.5 mm depth - allow for efficient PCB layout without sacrificing performance or accessibility. The 2196 series offers modular configurations to meet diverse industrial marketplace requirements.
Applications include industrial electronics, power supplies, automation systems, and other electrical equipment requiring reliable terminal connections. The robust construction and compliance certificates make this component a dependable choice for manufacturing and repair operations.
Supports 57A current rating for robust performance. Designed for through hole mount with one row of contacts. Suitable for wire sizes from 0.3 mm² to 8.3 mm² (22AWG to 8AWG). Operates safely at up to 300V AC voltage rating.
Equipped with standard 10.16 mm pitch and 18.3 mm width. Constructed with grey color housing and compliant with VDE, RoHS, and cULus standards. Compact dimensions: Length 20.92 mm, Depth 28.5 mm. Browse the extensive catalog of PCB Terminal Blocks and other electronic components at EnvMart to find compatible parts for your industrial and laboratory projects.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a current rating of 57A, making it suitable for robust performance in various applications.
It operates safely at a voltage rating of up to 300V AC, which is suitable for power distribution and control panels.
This terminal block accommodates wire sizes ranging from 0.3 mm² to 8.3 mm², which corresponds to AWG sizes 22 to 8.
The compact dimensions are 20.92 mm in length, 18.3 mm in width, and 28.5 mm in depth, allowing for efficient PCB layout.
It is designed for through hole mounting, which allows for secure soldering on printed circuit boards.
This terminal block is compliant with VDE, RoHS, and cULus standards, ensuring quality and regulatory compliance.
This model features two contacts arranged in a single row, providing a straightforward connection solution.
The housing of this terminal block is grey, which provides a standard appearance for custom electrical designs.
It is equipped with a standard pitch of 10.16 mm, facilitating compatibility with various PCB layouts.
This model has a horizontal orientation, which is typical for many PCB applications.
It is suitable for applications in industrial electronics, power supplies, automation systems, and other electrical equipment requiring reliable terminal connections.
The country of origin for this terminal block is China.
