Wurth Elektronik 2547 Series PCB Terminal Block 2-Contact 5 mm Pitch Through Hole 1 Row 691254710002
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 450V ac |
| Brand | Wurth Elektronik |
| Colour | Green |
| Orientation | Horizontal |
| Current | 24A |
| Length | 10.6mm |
| Depth | 18mm |
| Width | 11.2mm |
| Mount Type | Through Hole |
| Series | 2547 |
| Number of Rows | 1 |
| Pitch | 5mm |
| Standards/Approvals | cULus, VDE, RoHS |
| Number of Contacts | 2 |
| Minimum Wire Size mm² | 0.05mm² |
| Maximum Wire Size mm² | 3.31mm² |
| Minimum Wire Size AWG | 30AWG |
| Maximum Wire Size AWG | 12AWG |
Key Features
- Offers a high current rating of 24 amps for demanding electrical applications.
- Supports wire sizes ranging from 0.05 mm² to 3.31 mm² with AWG range from 30 to 12.
- Features a durable green color housing and horizontal orientation for easy PCB integration.
- Rated for voltage up to 450V AC ensuring robust insulation properties.
- Compact physical dimensions including length 10.6 mm, width 11.2 mm, and depth 18 mm optimize space usage on boards.
- Meets industry standards and approvals including cULus, VDE, and RoHS compliant materials.
Product Description
The Wurth Elektronik 691254710002 2547 Series PCB Terminal Block is a highly reliable electronic component engineered for efficient board level connection solutions. Featuring two contacts with a 5 mm pitch, this terminal block is optimized for through hole mounting in a single row configuration, ideal for compact electrical assemblies.
Designed to carry currents up to 24 amps, it supports a wide range of wire sizes from the minimal 0.05 mm² up to 3.31 mm², accommodating AWG sizes between 30 and 12 for versatile wiring applications. Its green-colored housing and horizontal orientation facilitate easy integration and identification on printed circuit boards.
Rated for a maximum voltage of 450 volts AC, the terminal block ensures electrical safety and insulation suitable for various industrial, electronic, and power distribution equipment. The product dimensions are precisely 10.6 mm in length, 11.2 mm in width, and 18 mm in depth, enabling efficient use of PCB space.
This terminal block fully complies with international standards including cULus, VDE certifications, and RoHS directives, guaranteeing adherence to quality and environmental standards.
Wurth Elektronik's 2547 Series terminal blocks provide modular and scalable solutions to meet diverse industrial marketplace requirements such as control cabinets, power supplies, measurement devices, and communication equipment.
Offers a high current rating of 24 amps for demanding electrical applications. Supports wire sizes ranging from 0.05 mm² to 3.31 mm² with AWG range from 30 to 12. Features a durable green color housing and horizontal orientation for easy PCB integration.
Rated for voltage up to 450V AC ensuring robust insulation properties. Compact physical dimensions including length 10.6 mm, width 11.2 mm, and depth 18 mm optimize space usage on boards. Meets industry standards and approvals including cULus, VDE, and RoHS compliant materials.
Explore more electronic components and PCB Terminal Blocks from Wurth Elektronik available at EnvMart for your electrical and electronic assembly needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It has a maximum current rating of 24 amps, making it suitable for demanding electrical applications.
This terminal block is rated for a maximum voltage of 450V AC, ensuring robust insulation properties.
It supports wire sizes ranging from 0.05 mm² to 3.31 mm², and AWG sizes from 30 to 12.
The dimensions are 10.6 mm in length, 11.2 mm in width, and 18 mm in depth.
It is designed for through hole mounting, optimized for compact electrical assemblies.
This model features two contacts in a single row configuration.
The housing is a durable green color, facilitating easy identification on printed circuit boards.
It meets industry standards and approvals including cULus, VDE, and is RoHS compliant.
It features a horizontal orientation for easy PCB integration.
The country of origin for this terminal block is India.
It is suitable for various applications including control cabinets, power supplies, measurement devices, and communication equipment.
The pitch size is 5 mm, which is standard for many PCB terminal blocks.
