onsemi Voltage Regulator 12V, SO 8-Pin, Low Dropout (LDO), High Accuracy, Surface Mount NCP3334DADJR2G
Specifications
| Country of Origin | India |
|---|---|
| Voltage | Regulators onsemi, Voltage Regulator 12V SO 8-Pin RS Stock No |
| Brand | onsemi |
| Height | 1.5mm |
| Length | 5mm |
| Model | NCP3334DADJR2G |
| Width | 4mm |
| Mount Type | Surface |
| Series | NCP3334 |
| Maximum Operating Temperature | 150°C |
| Package Type | SO |
| Polarity | Positive |
| Maximum Input Voltage | 12V |
| Minimum Input Voltage | 2.6V |
| Pin Count | 8 |
Key Features
- The device offers ±0.9% accuracy over line and load at 25°C.
- It features a low dropout voltage of 340 mV maximum at 500 mA load.
- Ultra-low noise of 38 μVrms ensures minimal signal interference.
- The regulator supports a supply voltage range from 2.6 V to 12 V.
- It includes reverse bias protection and thermal shutdown for enhanced reliability.
- Requires only 1.0 μF output capacitance for stable operation with any capacitor type.
- No minimum load current is needed for stability, making it suitable for diverse applications.
- Low shutdown current of 0.07 μA reduces power consumption in standby mode.
Product Description
onsemi NCP3334DADJR2G Voltage Regulator 12V SO 8-Pin is a precision low dropout (LDO) linear regulator designed for a broad range of consumer electronics applications requiring efficient voltage regulation with minimal noise and low power dissipation.
Featuring ±0.9% output voltage accuracy over line and load variations at 25°C, this device ensures stable voltage output under varying conditions. Its low dropout voltage of 340 mV at 500 mA load enables operation with low input-output voltage differentials, enhancing power efficiency.
The regulator supports an input voltage range from 2.6 V up to a maximum of 12 V, providing flexibility to various power source configurations. It features ultra-low noise distortion of 38 μVrms, ideal for sensitive signal processing and communications equipment.
Advanced protection features include reverse bias protection and thermal shutdown safeguards, enhancing device reliability and preventing damage due to overload or overheating. The regulator’s minimal shutdown current of 0.07 μA aids in reducing overall power consumption in standby scenarios.
The device is guaranteed stable with any capacitor type, including MLCC, using only 1.0 μF output capacitance and does not require a minimum load current for stability. Its compact SO 8-pin surface mount package measures 5 mm length, 4 mm width, and 1.5 mm height, facilitating easy integration into compact printed circuit board layouts.
Typical applications include PCMCIA cards, cellular phones, camcorders, networking systems such as DSL and cable modems, cable set-top boxes, MP3 and CD players, and display monitors.
The device’s compact and surface mount form factor suits modern electronics manufacturing. Stable output voltage with low noise meets stringent audio and communication device requirements. Thermal and reverse bias protections increase device safety and longevity in industrial and consumer products.
Wide supply voltage range enables versatile use across multiple electronic platforms. Low quiescent and shutdown current extends battery life in portable electronics. Explore EnvMart's comprehensive selection of semiconductor power management ICs for high-reliability industrial and consumer electronic applications.
Explore more products in our Voltage Regulator IC category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The output voltage accuracy is ±0.9% over line and load variations at 25°C.
The maximum dropout voltage is 340 mV at a load of 500 mA.
It supports a supply voltage range from 2.6 V to 12 V.
It features an ultra-low noise level of 38 μVrms, which minimizes signal interference.
This model comes in a compact SO 8-pin surface mount package.
The dimensions are 5 mm in length, 4 mm in width, and 1.5 mm in height.
No, it does not require a minimum load current for stability, making it suitable for diverse applications.
It includes thermal shutdown protection to prevent damage due to overheating.
The shutdown current is 0.07 μA, which helps reduce power consumption in standby mode.
The maximum operating temperature is 150°C.
Typical applications include PCMCIA cards, cellular phones, camcorders, and networking systems such as DSL and cable modems.
