TDK 1210 Shielded Wirewound Surface Mount Inductor with Ferrite Core 100μH ±10% 55mA NLFV32T-101K-EF
Specifications
| Country of Origin | Japan |
|---|---|
| Brand | TDK |
| Height | 2.2mm |
| Operating Temperature Range | - 40 to +105°C (including self-temperature rise) |
| Length | 3.2mm |
| Model | NLFV32T-101K-EF |
| Depth | 2.5mm |
| Packaging | Tape & Reel |
| Series | NLFV-EF |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 100μH |
| Standards/Approvals | RoHS |
| Package/Case | 1210 |
| Maximum DC Current | 55mA |
| Maximum DC Resistance | 2.64Ω |
| Inductance Tolerance | ±10 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 2.52MHz |
| Inductor Construction | Wirewound |
Key Features
- This surface mount inductor features a ferrite core and resin mold construction for enhanced magnetic shielding.
- It offers a compact 1210 package size with dimensions of 3.2mm length, 2.2mm height, and 2.5mm depth.
- The inductor operates reliably within a temperature range of -40°C to +105°C, including self-temperature rise.
- The maximum DC resistance of the component is rated at 2.64Ω, ensuring efficient current flow.
- It complies with RoHS standards and is suitable for use in smart meters, AV equipment, xDSL modems, and communications infrastructure.
- The device supports a maximum self-resonant frequency of 2.52MHz, optimizing performance in high-frequency applications.
- Packaging is provided on tape and reel for streamlined automated assembly processes.
- Termination style is surface mount, facilitating PCB mounting in compact designs.
Product Description
TDK NLFV32T-101K-EF is a 1210 size shielded wirewound surface mount inductor featuring a ferrite core and resin mold type wound construction designed for decoupling circuits. It delivers an inductance of 100μH with ±10% tolerance and supports a maximum DC current of 55mA. Its compact dimensions (3.2mm length, 2.2mm height, 2.5mm depth) make it ideal for space-constrained applications.
This inductor is magnetically shielded with ferrite powder embedded in the exterior mold resin, minimizing electromagnetic interference in sensitive electronic circuits. The component reliably operates across a wide temperature range from -40°C to +105°C, including self-temperature rise, ensuring stable performance under varying environmental conditions.
It shows a maximum DC resistance of 2.64Ω and a maximum self-resonant frequency of 2.52MHz, suitable for high-frequency signal filtering and power management in smart meters, audio/video equipment, xDSL devices, mobile base stations, industrial and communications infrastructure equipment.
The inductor is surface mount terminated and supplied in tape and reel packaging to support efficient automated assembly for high volume manufacturing. This inductor’s wirewound construction provides robustness and stable inductive performance.
RoHS-compliant manufacturing aligns with environmental standards. Its shielding reduces noise coupling in sensitive circuitry applications. Its wide operating temperature supports diverse industrial and commercial environments.
This TDK Surface Mount Inductor is an excellent choice for engineers designing compact, reliable electronic circuits in industrial, telecommunications, consumer electronics, and infrastructure sectors. Explore other high performance inductors and electronic components for your projects at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has an inductance value of 100μH with a tolerance of ±10%.
The maximum DC current for this inductor is rated at 55mA.
The dimensions of this inductor are 3.2mm in length, 2.2mm in height, and 2.5mm in depth.
It operates reliably within a temperature range of -40°C to +105°C, including self-temperature rise.
The maximum self-resonant frequency is 2.52MHz, which is suitable for high-frequency applications.
This inductor features a wirewound construction with a ferrite core, designed for enhanced magnetic shielding.
It is supplied in tape and reel packaging, which supports efficient automated assembly processes.
The maximum DC resistance is rated at 2.64Ω, ensuring efficient current flow.
Yes, it complies with RoHS standards, aligning with environmental regulations.
It is suitable for use in smart meters, audio/video equipment, xDSL modems, and communications infrastructure.
This model uses a surface mount termination style, facilitating PCB mounting in compact designs.
The country of origin for this inductor is Japan.
