ASSMANN WSW 26 Way Right Angle 2.29 mm Pitch Through Hole D-Sub Connector Male A-HDS 26 A-KG/T
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 250V |
| Brand | ASSMANN WSW |
| Orientation | Right Angle |
| Current | 3A |
| Model | A-HDS 26 A-KG/T |
| Mount Type | Through Hole |
| Housing Material | Polybutylene Terephthalate |
| Contact Material | Brass |
| Series | A-HDS |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -55°C |
| Pitch | 2.29mm |
| Contact Plating | Gold |
| Number of Contacts | 26 |
| Contact Gender | Male |
| Connector Gender | Male |
| Connector Type D | D-Sub |
| D-Sub Shell Size | DS-26 |
Key Features
- Right angle orientation ensures optimal PCB layout in confined spaces.
- 26 contact points provide robust signal transmission capacity.
- Gold-plated brass contacts enhance conductivity and corrosion resistance.
- Polybutylene terephthalate housing material provides durability and electrical insulation.
- Operates safely at voltages up to 250 V and currents up to 3 A.
- Suitable operating temperature range from -55°C to 105°C for varied environments.
- Through hole mount type ensures secure PCB attachment and mechanical stability.
- Male gender connector designed for easy mating with female counterparts.
Product Description
ASSMANN WSW A-HDS 26 A-KG/T is a 26 Way Right Angle Through Hole D-Sub Connector Male featuring a 2.29 mm pitch designed for electronic and power connector applications requiring reliable, high-density connections. This connector is especially suitable for complex PCB layouts where space optimization is critical due to its right angle orientation.
Constructed with brass contact material and gold plating, the connector ensures excellent conductivity and long-term durability, maintaining a stable electrical connection. The housing is made of polybutylene terephthalate, offering robust mechanical strength and electrical insulation, making it appropriate for demanding industrial environments.
Rated for a maximum current of 3 A and voltage of 250 V, it provides dependable performance in a wide temperature range from -55°C up to 105°C, accommodating diverse operating conditions. The through-hole mounting type offers secure attachment to printed circuit boards, supporting manufacturing processes and ensuring stability against mechanical stress.
This D-Sub Connector accommodates 26 contacts utilizing the DS-26 shell size, making it ideal for applications in electronics manufacturing, industrial automation, and computing. Its standardized contact pitch of 2.29 mm supports efficient electrical transmission while simplifying design integration.
Right angle orientation for space-saving PCB mount. Gold-plated brass contacts for superior conductivity and corrosion resistance. Durable polybutylene terephthalate housing for mechanical and electrical performance. Through-hole mounting type for robust PCB attachment.
Operating temperature from -55°C to 105°C suits varied environments. Current rating of 3 A and voltage rating of 250 V. 26 contact connectors with DS-26 shell size and 2.29 mm pitch. Male connector gender for standard D-Sub mating.
Applicable in industrial, electronics manufacturing, computing, and power connectors.
This product is made in China and is provided new and ready for integration into electronic assemblies. The ASSMANN WSW A-HDS 26 A-KG/T is an essential component in industries where reliable high-density PCB connections are required. Explore more industrial-grade electronic connectors on EnvMart for your specific application needs.
