Molex KK 254 Series Right Angle Through Hole Pin Header, 9 Contacts, 2.54 mm Pitch, 1 Row, Unshrouded 22-05-7098
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 250V |
| Brand | Molex |
| Orientation | Right Angle |
| Current | 4A |
| Mount Type | Through Hole |
| Housing Material | Nylon |
| Contact Material | Brass |
| Series | KK 254 |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Tin |
| Number of Contacts | 9 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 3.8mm |
| Mating Pin Length | 2.54mm |
Key Features
- Designed for wire-to-board connection with right angle orientation.
- Featuring 9 brass contacts plated with tin for reliable conductivity.
- Pitch spacing of 2.54 mm suitable for standard PCB layouts.
- Housing made from UL 94V-0 rated Nylon for flame resistance.
- Tail pin length is 3.8 mm and mating pin length is 2.54 mm for secure soldering.
- Supports a current rating of up to 4A and voltage rating of 250V.
- Operates reliably between -40°C and 105°C temperature range.
- Single row, unshrouded style for ease of board placement.
Product Description
Molex 22-05-7098 KK 254 Series Right Angle Through Hole Pin Header is a high-quality PCB connector designed for wire-to-board applications requiring a reliable 9-contact interface with 2.54 mm pitch. Crafted to ensure strong electrical connections, this pin header features a brass contact material with tin plating for enhanced durability and conductivity.
The connector housing is constructed from UL 94V-0 rated Nylon, providing excellent flame retardance and robust mechanical strength. Its right angle orientation facilitates efficient PCB designs and assembly processes. With a single row of 9 male pins, each with a 3.8 mm tail pin length and 2.54 mm mating pin length, the header supports solder termination through-hole mounting, ensuring solid mechanical and electrical retention.
This header supports a maximum current rating of 4A and voltage up to 250V, making it suitable for a wide range of electronic applications including industrial, commercial, and laboratory equipment. Its operating temperature range from -40°C to 105°C adds to its versatility in various environments.
The unshrouded design allows easy access to contacts while maintaining reliable connection integrity. This Molex KK 254 Series product is ideal for secure wire-to-board connections in electronics manufacturing, automation systems, and embedded designs.
Designed for wire-to-board connection with right angle orientation. Featuring 9 brass contacts plated with tin for reliable conductivity. Pitch spacing of 2.54 mm suitable for standard PCB layouts. Housing made from UL 94V-0 rated Nylon for flame resistance.
Tail pin length is 3.8 mm and mating pin length is 2.54 mm for secure soldering. Supports a current rating of up to 4A and voltage rating of 250V. Operates reliably between -40°C and 105°C temperature range. Single row, unshrouded style for ease of board placement.
Explore more electronics components and PCB connectors in our catalog to find compatible parts and enhance your project design at EnvMart.
Explore more products in our PCB Headers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a maximum current rating of 4A and a voltage rating of 250V.
The pitch spacing of the contacts is 2.54 mm, suitable for standard PCB layouts.
The housing is made from UL 94V-0 rated Nylon, and the contacts are brass plated with tin for reliable conductivity.
It operates reliably between -40°C and 105°C, making it versatile for various environments.
This pin header features 9 contacts arranged in a single row.
It utilizes through-hole mounting for secure solder termination.
The tail pin length is 3.8 mm, which aids in secure soldering.
The mating pin length is 2.54 mm, designed for effective connection.
This model features a right angle orientation, facilitating efficient PCB designs.
This pin header is unshrouded, allowing easy access to contacts while maintaining connection integrity.
It is designed for wire-to-board connections, making it suitable for various electronic applications.
The country of origin for this product is India.
