Molex SL Series Right Angle Through Hole PCB Header 6 Contacts, 2.54 mm Pitch, 1 Row, Shrouded 70553-0040

Molex 70553-0040 SL Series Right Angle Through Hole PCB Header is a high-quality connector designed for printed circuit board applications requiring 6 contact points with a 2.54 mm pitch in a single row configuration. The shrouded design and right angle orientation offer enhanced reliability and protection against accidental disconnection, making it suitable for industrial and commercial electronics manufacturing.

The housing is constructed from a high temperature thermoplastic material, allowing operation in elevated temperature environments from -40°C up to 105°C. The phosphor bronze contacts combined with tin plating guarantee dependable electrical connectivity and mechanical endurance under typical use conditions.

This connector supports wire-to-board systems and terminates via soldering through the PCB, with tail pins measuring 3.3 mm for accurate and secure placement. It is rated for 250 V and 3 A current, making it suitable for various low power and signal applications in industrial automation, instrumentation, and control systems.

While no specific standards or approvals are cited, this Molex SL Series header is widely used in electronics manufacturing and assembly for robust, compact, and reliable connections.

Designed for wire-to-board connector applications in electronic assemblies. High temperature thermoplastic housing ensures durability and heat resistance. Phosphor bronze contact material provides reliable conductivity and strength.

Right angle orientation with shrouded header improves connection security and protection. Suitable for solder termination through hole mounting on PCB. Contacts feature tin plating for enhanced corrosion resistance. Rated voltage of 250 V and current capacity of 3 A for reliable power handling.

Operating temperature range from -40°C to 105°C ensures performance in harsh environments. Tail pin length of 3.3 mm facilitates secure soldering on PCB. Meets industrial standards without specific approvals, intended for broad electronics use.

This product is sourced from the United States and is ideal for industrial, manufacturing, electronics assembly, laboratory, and commercial applications requiring dependable PCB connections. Explore more Molex electronic components on EnvMart for complete system integration solutions.
