Wurth Elektronik Wirewound Surface Mount Inductor 150μH ±30% 850mA Shielded Ferrite Core 1028 Package 744065151

Wurth Elektronik 744065151 wirewound surface mount inductor provides an inductance value of 150μH with a tolerance of ±30%, designed specifically for compact electronic applications requiring high current capability and magnetic shielding.

The device comes in a standard 1028 package measuring 10mm in length, 2.8mm in height, and 10mm in depth, making it highly suitable for space-constrained PCB layouts. Constructed with a ferrite core and wirewound inductor coil, the magnetic shielding feature significantly reduces leakage magnetic fields enhancing circuit reliability.

This inductor supports a maximum DC current of 850mA and maintains a maximum DC resistance of 680mΩ, ensuring efficient current conduction and thermal management.

Rated for a temperature range from -40°C to 125°C, it complies with rigorous automotive standard AEC-Q200 and industry standards such as RoHS, IEC 60286-3:2013, IEC 61249-2-21, IPC/JEDEC J-STD-020E, JEDEC JS709B, and REACH, confirming its robustness for industrial and automotive use.

Its self-resonant frequency is 5MHz, making it suitable for DC/DC converters, embedded computing devices, portable power applications like PDAs, digital cameras, as well as telemetric and mobile data gathering systems.

The surface mount termination style and tape & reel packaging facilitate automated assembly processes and efficient manufacturing workflows. The inductor features a 1028 package size suitable for surface mount applications.

It is magnetically shielded to minimize leakage fields and improve performance. Designed to operate reliably between -40°C and 125°C for industrial and automotive environments. Complies with automotive standard AEC-Q200 and multiple RoHS and IEC standards.

Maximum DC resistance is 680mΩ, maintaining efficient current flow. Its wirewound construction enhances durability and inductance stability. Termination style is surface mount, ideal for PCB assembly automation. The maximum self-resonant frequency is 5MHz allowing use in power and signal conditioning circuits.

Packaged in tape and reel format for efficient high volume placement machines. Applications include portable power devices, DC/DC converters, embedded PCs, and telemetric equipment. Explore more Surface Mount Inductors and electronic components at EnvMart to meet your design and manufacturing needs.
