Samtec Pin Header, Straight Surface Mount, 8 Contacts, 2 Row, 2.54 mm Pitch, Liquid Crystal Polymer Housing TSM-104-01-S-DV
Specifications
| Country of Origin | United States |
|---|---|
| Voltage | 475V |
| Brand | Samtec |
| Orientation | Straight |
| Current | 4A |
| Model | TSM-104-01-S-DV |
| Mount Type | Surface |
| Special Features | Designed specifically for surface mount applications with many options to facilitate processing |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Series | TSM |
| Termination | Surface mount, mixed technology |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 8 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 1.27mm |
| Mating Pin Length | 5.84mm |
| Contact System | .025" (0.635 mm) square post |
Key Features
- Manufactured with liquid crystal polymer housing for durability.
- Contacts are made of phosphor bronze and plated with gold for reliable conductivity.
- Supports a maximum current of 4A and voltage rating of 475V.
- Designed with surface mount termination and solder type connection.
- Operating temperature ranges from -55°C to 125°C for broad environmental compatibility.
- Contact posts are .025" square with tail pin length of 1.27mm and mating pin length of 5.84mm.
- Unshrouded, straight orientation with wire-to-board connector system.
- Suitable for surface mounting on PCBs in electronic applications.
Product Description
Samtec TSM-104-01-S-DV pin header is a precision-engineered electronic connector designed for surface mount applications requiring reliable wire-to-board connections. This model features 8 male contacts arranged in 2 rows with a standard 2.54 mm pitch, making it compatible with many PCB designs.
The housing is constructed from liquid crystal polymer, offering excellent mechanical strength and temperature resistance. The contact pins are phosphor bronze plated with gold to ensure optimal conductivity and resistance to corrosion.
This pin header supports a current rating of 4 amperes and a voltage rating up to 475 volts, making it suitable for a wide range of electronic circuitry in industrial, commercial, and manufacturing environments.
It operates reliably in temperatures ranging from -55°C to 125°C, supporting harsh conditions and extensive lifecycle requirements. The termination type is surface mount soldering, optimized for automated assembly processes.
The connector system utilizes a .025" (0.635 mm) square post contact design with a tail pin length of 1.27 mm and a mating pin length of 5.84 mm, maintaining consistent mechanical and electrical performance.
Manufactured with liquid crystal polymer housing for durability. Gold plated phosphor bronze contacts ensure reliable conductivity. Unshrouded, straight orientation for easy access and installation. Designed for surface mount termination on PCBs.
Operating temperature range from -55°C to 125°C. High current and voltage ratings of 4A and 475V respectively. Wire-to-board connector system suitable for multiple applications.
This pin header is ideal for electronics manufacturing, industrial control systems, telecommunications equipment, and other applications requiring robust, high-performance PCB connectors. Its precise construction ensures consistent mating cycles and long service life.
Category choice aligns this product with PCB connectors and wire housings under electronics components, supporting easy discovery for professionals in electronics design and assembly.
Discover more high-quality PCB connector solutions and Samtec products at EnvMart by exploring our extensive electronic components catalog.
Explore more products in our PCB Connectors & Wire Housings category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This pin header supports a maximum current of 4A and a voltage rating of 475V.
It operates reliably in temperatures ranging from -55°C to 125°C.
The housing is made from liquid crystal polymer, while the contacts are made of phosphor bronze plated with gold.
This model features 8 male contacts arranged in 2 rows with a standard 2.54 mm pitch.
It uses a surface mount termination with a solder type connection.
The tail pin length is 1.27 mm, and the mating pin length is 5.84 mm.
This pin header has a straight orientation and is unshrouded.
It utilizes a wire-to-board connector system, suitable for surface mounting on PCBs.
The contact system features .025" (0.635 mm) square post contacts.
The pin header is manufactured in the United States.
It is designed specifically for surface mount applications with many options to facilitate processing.
